Table 3 SHIELDED SPLICE KIT COMPONENT PART NUMBERS (Continued)
Splice Kit
Kit Component
Type Part Number Quantity Supplier
D-150-0362
Conductor Splice BACS52K3N 1 Tyco
Seal Insert D-097-10-01-01 2 Tyco
Shield Material D-096-22-02-01 1 Tyco
Sleeve, Outer D-098-93-30-04 1 Tyco
Sleeve, Seal D-098-93-33-01 1 Tyco
Solder Sleeve SO96-3-00 2 Tyco
D-150-0363
Conductor Splice BACS52K1N 2 Tyco
Seal Insert D-097-10-01-01 2 Tyco
Shield Material D-096-22-07-06 1 Tyco
Sleeve, Outer D-098-93-30-05 1 Tyco
Sleeve, Seal D-098-93-34-01 2 Tyco
Solder Sleeve SO96-3-00 2 Tyco
D-150-0364
Conductor Splice BACS52K2N 2 Tyco
Seal Insert D-097-10-01-01 2 Tyco
Shield Material D-096-22-03-03 1 Tyco
Sleeve, Outer D-098-93-30-05 1 Tyco
Sleeve, Seal D-098-93-34-01 2 Tyco
Solder Sleeve SO96-3-00 2 Tyco
D-150-0365
Conductor Splice BACS52K2N 3 Tyco
Seal Insert D-097-92-13-01 2 Tyco
Shield Material D-096-22-03-03 1 Tyco
Sleeve, Outer D-098-93-30-06 1 Tyco
Sleeve, Seal D-098-93-30-02 3 Tyco
Solder Sleeve SO96-3-00 2 Tyco
D-150-0366
Conductor Splice BACS52K1N 1 Tyco
Seal Insert D-097-92-19-02 2 Tyco
Shield Material D-096-22-07-01 1 Tyco
Sleeve, Outer D-098-93-30-04 1 Tyco
Sleeve, Seal D-098-93-34-01 1 Tyco
Solder Sleeve SO96-2-00 1 Tyco
Solder Sleeve SO96-3-00 1 Tyco
ASSEMBLY OF BACS52P SERIES AND D-150-0300 SERIES SHIELDED SPLICE ASSEMBLIES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-20
Page 34
Jun 15/2021D6-54446
