Boeing 707 - Page 735

Table 3 SHIELDED SPLICE KIT COMPONENT PART NUMBERS (Continued)
Splice Kit
Kit Component
Type Part Number Quantity Supplier
D-150-0367
Conductor Splice BACS52K2N 1 Tyco
Seal Insert D-097-92-20-03 2 Tyco
Shield Material D-096-22-07-07 1 Tyco
Sleeve, Outer D-098-93-30-01 1 Tyco
Sleeve, Seal D-098-93-34-01 1 Tyco
Solder Sleeve SO96-2-00 1 Tyco
Solder Sleeve SO96-3-00 1 Tyco
D-150-0368
Conductor Splice BACS52K3N 1 Tyco
Seal Insert D-097-10-01-01 2 Tyco
Shield Material D-096-22-02-01 1 Tyco
Sleeve, Outer D-098-93-30-04 1 Tyco
Sleeve, Seal D-098-93-33-01 1 Tyco
Solder Sleeve SO96-2-00 1 Tyco
Solder Sleeve SO96-3-00 1 Tyco
D-150-0369
Conductor Splice BACS52K2N 2 Tyco
Seal Insert D-097-10-01-01 2 Tyco
Shield Material D-096-22-03-03 1 Tyco
Sleeve, Outer D-098-93-30-05 1 Tyco
Sleeve, Seal D-098-93-34-01 2 Tyco
Solder Sleeve SO96-2-00 1 Tyco
Solder Sleeve SO96-3-00 1 Tyco
D-150-0370
Conductor Splice BACS52K2N 2 Tyco
Seal Insert D-097-10-01-01 2 Tyco
Shield Material D-096-22-03-03 1 Tyco
Sleeve, Outer D-098-93-30-05 1 Tyco
Sleeve, Seal D-098-93-34-01 2 Tyco
Solder Sleeve SO96-4-00 1 Tyco
Solder Sleeve SO96-3-00 1 Tyco
ASSEMBLY OF BACS52P SERIES AND D-150-0300 SERIES SHIELDED SPLICE ASSEMBLIES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-20
Page 35
Jun 15/2021D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
