Table 3 BACT12AC GENERAL PURPOSE TERMINAL LUG PART NUMBERS (Continued)
Crimp Barrel Size
(Wire Size Range)
(AWG)
CAU Range
Insulation
Color
Stud Hole Size Boeing Standard
Minimum Maximum
4 332 526 Yellow
8 BACT12AC74
10 BACT12AC75
10 BACT12AC71
1/4 BACT12AC23
5/16 BACT12AC24
3/8 BACT12AC25
1/2 BACT12AC61
2 527 837 Red
10 BACT12AC70
1/4 BACT12AC26
5/16 BACT12AC72
3/8 BACT12AC27
1/2 BACT12AC28
1/0 838 1195 Blue
1/4 BACT12AC32
5/16 BACT12AC73
3/8 BACT12AC33
1/2 BACT12AC34
2/0 1196 1505 Yellow
5/16 BACT12AC35
3/8 BACT12AC36
1/2 BACT12AC37
4/0 1901 2310 Blue
3/8
BACT12AC40
BACT12AC60
1/2 BACT12AC41
5/8 BACT12AC59
7/8 BACT12AC42
Table 4
SUPPLIER PART NUMBERS FOR BACT12AC TERMINAL LUGS
Boeing Standard Part Number Supplier
BACT12AC1
36149 Tyco/AMP
AA-820-06 ETC
R1881SN Hollingsworth
BACT12AC10
320564 Tyco/AMP
BB-818-38 ETC
R1908SN Hollingsworth
ASSEMBLY OF INSULATED AND UNINSULATED TERMINAL LUGS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-11
Page 8
Oct 15/2015D6-54446
