Table 3 BACT12AC GENERAL PURPOSE TERMINAL LUG PART NUMBERS (Continued)
Crimp Barrel Size
(Wire Size Range)
(AWG)
CAU Range
Insulation
Color
Stud Hole Size Boeing Standard
Minimum Maximum
22 - 18 7 24 Red
4 BACT12AC48
6
BACT12AC1
BACT12AC2
8 BACT12AC49
10 BACT12AC3
1/4 BACT12AC50
5/16 BACT12AC4
3/8 BACT12AC5
1/2 BACT12AC51
16 - 14 15 51 Blue
4 BACT12AC52
6
BACT12AC6
BACT12AC7
8 BACT12AC53
10 BACT12AC8
1/4 BACT12AC54
5/16 BACT12AC9
3/8 BACT12AC10
1/2 BACT12AC55
12 - 10 43 138 Yellow
6 BACT12AC11
8 BACT12AC56
10 BACT12AC12
1/4 BACT12AC57
5/16 BACT12AC13
3/8 BACT12AC14
1/2 BACT12AC58
8 132 208 Red
8 BACT12AC62
10 BACT12AC15
1/4 BACT12AC16
5/16 BACT12AC17
3/8 BACT12AC18
6 209 331 Blue
10 BACT12AC19
1/4 BACT12AC20
5/16 BACT12AC21
3/8 BACT12AC22
ASSEMBLY OF INSULATED AND UNINSULATED TERMINAL LUGS
