Table 7
BACT12AR RESTRICTIVE ENTRY TERMINAL LUG PART NUMBERS
Crimp Barrel Size
(Wire Size)
(AWG)
CAU Range Insulation Color
Stud Hole
Size
Boeing Standard
Minimum Maximum Sleeve Band
24 4 5 Yellow Blue
4 BACT12AR241
6 BACT12AR242
8 BACT12AR243
10
BACT12AR244
BACT12AR245
22 5 8 Red Green
4 BACT12AR221
6 BACT12AR222
8 BACT12AR223
10 BACT12AR224
1/4 BACT12AR225
5/16 BACT12AR226
3/8 BACT12AR227
20 8 12 Red Red
4 BACT12AR201
6 BACT12AR202
8 BACT12AR203
10 BACT12AR204
1/4 BACT12AR205
5/16 BACT12AR206
3/8 BACT12AR207
18 12 19 Red White
4 BACT12AR181
6 BACT12AR182
8 BACT12AR183
10 BACT12AR184
1/4 BACT12AR185
5/16 BACT12AR186
3/8 BACT12AR187
16 19 26 Blue Blue
6 BACT12AR161
8 BACT12AR162
10 BACT12AR163
1/4 BACT12AR164
5/16 BACT12AR165
3/8 BACT12AR166
ASSEMBLY OF INSULATED AND UNINSULATED TERMINAL LUGS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-11
Page 15
Oct 15/2015D6-54446
