Table 7 BACT12AR RESTRICTIVE ENTRY TERMINAL LUG PART NUMBERS (Continued)
Crimp Barrel Size
(Wire Size)
(AWG)
CAU Range Insulation Color
Stud Hole
Size
Boeing Standard
Minimum Maximum Sleeve Band
14 27 41 Blue Green
6 BACT12AR141
8 BACT12AR142
10 BACT12AR143
5/16 BACT12AR144
12 42 65 Yellow Yellow
6 BACT12AR121
8 BACT12AR122
10 BACT12AR123
1/4 BACT12AR124
5/16 BACT12AR125
3/8 BACT12AR126
10 66 105 Yellow Brown
6 BACT12AR101
8 BACT12AR102
10 BACT12AR103
1/4 BACT12AR104
5/16 BACT12AR105
3/8 BACT12AR106
Table 8
SUPPLIER PART NUMBERS FOR BACT12AR TERMINAL LUGS
Boeing Standard Part Number Supplier
BACT12AR101 2-36161-6 AMP
BACT12AR102 2-320568-3 AMP
BACT12AR103 2-36161-4 AMP
BACT12AR104 2-320569-6 AMP
BACT12AR105 2-320576-3 AMP
BACT12AR106 2-320577-2 AMP
BACT12AR121 2-36161-5 AMP
BACT12AR122 2-320568-2 AMP
BACT12AR123 2-36161-3 AMP
BACT12AR124 2-320569-5 AMP
BACT12AR125 2-320576-2 AMP
BACT12AR126 2-320577-1 AMP
BACT12AR141 51864-8 AMP
BACT12AR142 1-51864-1 AMP
ASSEMBLY OF INSULATED AND UNINSULATED TERMINAL LUGS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-11
