Table 39
CONNECTIONS
Wire Connection Wire Connected to
A Splice B and C
(1) Remove approximately 0.05 inch from each end of the shield material with a pair of scissors or an
equivalent tool.
NOTE: The shield material has fused ends that hold the ends of the strands of the shield
together.
(2) If the splice kit has seal inserts and different size solder sleeves:
(a) Put these components on Cable A in this sequence:
• The outer sleeve
• A seal insert, if a build-up sleeve is not specified for the cable
• The small solder sleeve
• The shield material
• The large solder sleeve
• The seal sleeve.
Make sure that:
• The small end of the small solder sleeve is put on the cable first
• The large end of the large solder sleeve is put on the cable first.
(b) Put the other seal insert on Cable B, if a build-up sleeve is not specified for the cable.
(3) If the splice kit has seal inserts and same size solder sleeves:
(a) Put these splice assembly components on Cable A in this sequence:
• The outer sleeve
• A seal insert, if a build-up sleeve is not specified for the cable
• A solder sleeve
• The shield material
• The other solder sleeve
• The seal sleeve.
Make sure that:
• The small end of the small solder sleeve is put on the cable first
• The large end of the large solder sleeve is put on the cable first.
(b) Put the seal insert on Cable B, if a build-up sleeve is not specified for the cable.
(4) If the splice kit does not have seal inserts and has different size solder sleeves put these
components on Cable A in this sequence:
• The outer sleeve
• The small solder sleeve
• The shield material
ASSEMBLY OF BACS52P SERIES AND D-150-0300 SERIES SHIELDED SPLICE ASSEMBLIES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-20
Page 153
Jun 15/2021D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
