Table 2 SHIELDED SPLICE KIT COMPONENT PART NUMBERS (Continued)
Splice Kit
Kit Component
Type Part Number Quantity Supplier
BACS52T1N2D
Conductor Splice BACS52K1N 2 Tyco
Seal Insert BACS13DL3 2 Tyco
Shield Material BACS13DK5 1 Tyco
Sleeve, Outer BACT63E6G 1 Tyco
Sleeve, Seal BACS13DJ1 2 Tyco
Solder Sleeve D-208-03 2 Tyco
BACS52T1T1B
Conductor Splice BACS52K1 1 Tyco
Shield Material BACS13DR1 1 Tyco
Sleeve, Outer BACT63E3E 1 Tyco
Sleeve, Seal BACS13DJ1 1 Tyco
Solder Sleeve D-208-06 2 Tyco
BACS52T1T2C
Conductor Splice BACS52K1 2 Tyco
Seal Insert BACS13DL2 2 Tyco
Shield Material BACS13DR4 1 Tyco
Sleeve, Outer BACT63E4G 1 Tyco
Sleeve, Seal BACS13DJ1 2 Tyco
Solder Sleeve D-208-07 2 Tyco
BACS52T1T2D
Conductor Splice BACS52K1 2 Tyco
Seal Insert BACS13DL3 2 Tyco
Shield Material BACS13DR5 1 Tyco
Sleeve, Outer BACT63E6G 1 Tyco
Sleeve, Seal BACS13DJ1 2 Tyco
Solder Sleeve D-208-08 2 Tyco
BACS52T2N1B
Conductor Splice BACS52K2N 1 Tyco
Shield Material BACS13DK1 1 Tyco
Sleeve, Outer BACT63E3E 1 Tyco
Sleeve, Seal BACS13DJ2 1 Tyco
Solder Sleeve D-208-01 2 Tyco
BACS52T2N1C
Conductor Splice BACS52K2N 1 Tyco
Shield Material BACS13DK8 1 Tyco
Sleeve, Outer BACT63E4E 1 Tyco
Sleeve, Seal BACS13DJ2 1 Tyco
Solder Sleeve D-208-02 1 Tyco
Solder Sleeve D-208-03 1 Tyco
ASSEMBLY OF BACS52T SERIES SHIELDED SPLICE ASSEMBLIES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-21
Page 6
Feb 15/2021D6-54446
