Table 2 SHIELDED SPLICE KIT COMPONENT PART NUMBERS (Continued)
Splice Kit
Kit Component
Type Part Number Quantity Supplier
BACS52T2N2C
Conductor Splice BACS52K2N 2 Tyco
Seal Insert BACS13DL3 2 Tyco
Shield Material BACS13DK8 1 Tyco
Sleeve, Outer BACT63E4G 1 Tyco
Sleeve, Seal BACS13DJ2 2 Tyco
Solder Sleeve D-208-02 1 Tyco
Solder Sleeve D-208-03 1 Tyco
BACS52T2N2D
Conductor Splice BACS52K2N 2 Tyco
Seal Insert BACS13DL4 2 Tyco
Shield Material BACS13DK9 1 Tyco
Sleeve, Outer BACT63E6G 1 Tyco
Sleeve, Seal BACS13DJ2 2 Tyco
Solder Sleeve D-208-03 1 Tyco
Solder Sleeve D-208-04 1 Tyco
BACS52T2N2E
Conductor Splice BACS52K2N 2 Tyco
Shield Material BACS13DK10 1 Tyco
Sleeve, Outer BACT63E8G 1 Tyco
Sleeve, Seal BACS13DJ2 2 Tyco
Solder Sleeve D-208-05 1 Tyco
BACS52T2N3C
Conductor Splice BACS52K2N 3 Tyco
Seal Insert BACS13DL3 2 Tyco
Shield Material BACS13DK5 1 Tyco
Sleeve, Outer BACT63E4G 1 Tyco
Sleeve, Seal BACS13DJ2 3 Tyco
Solder Sleeve D-208-03 2 Tyco
BACS52T2N3D
Conductor Splice BACS52K2N 3 Tyco
Seal Insert BACS13DL3 2 Tyco
Shield Material BACS13DK5 1 Tyco
Sleeve, Outer BACT63E6G 1 Tyco
Sleeve, Seal BACS13DJ2 3 Tyco
Solder Sleeve D-208-03 2 Tyco
ASSEMBLY OF BACS52T SERIES SHIELDED SPLICE ASSEMBLIES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-21
Page 7
Feb 15/2021D6-54446
