Table 2 SHIELDED SPLICE KIT COMPONENT PART NUMBERS (Continued)
Splice Kit
Kit Component
Type Part Number Quantity Supplier
BACS52T2N4D
Conductor Splice BACS52K2N 4 Tyco
Seal Insert BACS13DL3 2 Tyco
Shield Material BACS13DK9 1 Tyco
Sleeve, Outer BACT63E6G 1 Tyco
Sleeve, Seal BACS13DJ2 4 Tyco
Solder Sleeve D-208-03 1 Tyco
Solder Sleeve D-208-04 1 Tyco
BACS52T2T1B
Conductor Splice BACS52K2 1 Tyco
Shield Material BACS13DR1 1 Tyco
Sleeve, Outer BACT63E3E 1 Tyco
Sleeve, Seal BACS13DJ2 1 Tyco
Solder Sleeve D-208-06 2 Tyco
BACS52T2T1C
Conductor Splice BACS52K2 1 Tyco
Shield Material BACS13DR8 1 Tyco
Sleeve, Outer BACT63E4E 1 Tyco
Sleeve, Seal BACS13DJ2 1 Tyco
Solder Sleeve D-208-07 1 Tyco
Solder Sleeve D-208-08 1 Tyco
BACS52T2T2C
Conductor Splice BACS52K2 2 Tyco
Seal Insert BACS13DL3 2 Tyco
Shield Material BACS13R89 1 Tyco
Sleeve, Outer BACT63E4G 1 Tyco
Sleeve, Seal BACS13DJ2 2 Tyco
Solder Sleeve D-208-07 1 Tyco
Solder Sleeve D-208-08 1 Tyco
BACS52T2T2D
Conductor Splice BACS52K2 2 Tyco
Seal Insert BACS13DL4 2 Tyco
Shield Material BACS13DR9 1 Tyco
Sleeve, Outer BACT63E6G 1 Tyco
Sleeve, Seal BACS13DJ2 2 Tyco
Solder Sleeve D-208-08 1 Tyco
Solder Sleeve D-208-09 1 Tyco
ASSEMBLY OF BACS52T SERIES SHIELDED SPLICE ASSEMBLIES
