Table 17 BACT12M AND 280U0010-1 HIGH TEMPERATURE TERMINAL LUG PART NUMBERS
(Continued)
Crimp Barrel Size
(Wire Size Range)
(AWG)
CAU Range
Stud Hole Size Boeing Standard
Minimum Maximum
1/0 831 1119
1/4 BACT12M25-1
5/16 BACT12M25-2
3/8 BACT12M25-3
1/2 BACT12M25-4
5/8 BACT12M25-5
2/0 1049 1458
1/4 BACT12M26-1
5/16 BACT12M26-2
3/8 BACT12M26-3
3/8 BACT12M26-3N
1/2 BACT12M26-4
5/8 BACT12M26-5
3/4 BACT12M26-6
3/0 1323 1810
5/16 BACT12M27-1
3/8 BACT12M27-2
1/2 BACT12M27-3
5/8 BACT12M27-4
4/0 1666 2257
5/16 BACT12M28-1
3/8
BACT12M28-2
280U0010-1
1/2 BACT12M28-3
5/8 BACT12M28-4
3/4 BACT12M28-5
7/8 BACT12M28-6
Table 18
SUPPLIER PART NUMBERS FOR BACT12M TERMINAL LUGS
Boeing Standard Part Number Supplier
BACT12M1 322362 AMP/Tyco
BACT12M1-1 YAV1C-L6NK Burndy
BACT12M1-2 YAV1C-L1NK Burndy
BACT12M1-3 YAV1C-L2NK Burndy
BACT12M1-4 YAV1C-LNK Burndy
BACT12M1-5 YAV1C-L3NK Burndy
BACT12M130 323199 AMP/Tyco
ASSEMBLY OF INSULATED AND UNINSULATED TERMINAL LUGS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-11
Page 26
Feb 15/2021D6-54446
