Table 17 BACT12M AND 280U0010-1 HIGH TEMPERATURE TERMINAL LUG PART NUMBERS
(Continued)
Crimp Barrel Size
(Wire Size Range)
(AWG)
CAU Range
Stud Hole Size Boeing Standard
Minimum Maximum
12 - 10 43 138
6 BACT12M139
8 BACT12M146
10 BACT12M140
1/4 BACT12M141
5/16 BACT12M144
3/8 BACT12M145
8 131 181
8 BACT12M8-1
10 BACT12M8-2
1/4 BACT12M8-3
5/16 BACT12M8-4
3/8 BACT12M8-5
1/2 BACT12M8-6
6 206 288
10 BACT12M6-1
1/4 BACT12M6-2
5/16 BACT12M6-3
3/8 BACT12M6-4
1/2 BACT12M6-5
4 327 457
10 BACT12M4-1
1/4 BACT12M4-2
5/16 BACT12M4-3
3/8 BACT12M4-4
1/2 BACT12M4-5
2 524 735
10 BACT12M2-1
1/4 BACT12M2-2
5/16 BACT12M2-3
3/8 BACT12M2-4
1/2 BACT12M2-5
1 662 878
10 BACT12M1-1
1/4 BACT12M1-2
5/16 BACT12M1-3
3/8 BACT12M1-4
1/2 BACT12M1-5
ASSEMBLY OF INSULATED AND UNINSULATED TERMINAL LUGS
