Dell PowerConnect 5424

To Next Page

To Previous Page

Voice VLAN 475

Voice VLAN VLAN ID: 8

CoS: 6

Remark: Yes

Interface Enabled Secure Activated

g1 Yes Yes Yes

g2 Yes Yes No

g3 Yes Yes Yes

g4 Yes Yes Yes

g5 No No

g6 No No

g7 No No

g8 No No

g9 No No
