504 802.1x Commands

Examples

The following example displays 802.1X statistics for the specified interface.

The following table describes the significant fields shown in the display:

Switch# show dot1x statistics ethernet g1

EapolFramesRx: 11

EapolFramesTx: 12

EapolStartFramesRx: 1

EapolLogoffFramesRx: 1

EapolRespIdFramesRx: 3

EapolRespFramesRx: 6

EapolReqIdFramesTx: 3

EapolReqFramesTx: 6

InvalidEapolFramesRx: 0

EapLengthErrorFramesRx: 0

LastEapolFrameVersion: 1

LastEapolFrameSource: 0008.3b79.8787

Field Description

EapolFramesRx The number of valid EAPOL frames of any type that have been received by this

Authenticator.

EapolFramesTx The number of EAPOL frames of any type that have been transmitted by this

Authenticator.

EapolStartFramesRx The number of EAPOL Start frames that have been received by this Authenticator.

EapolLogoffFramesRx The number of EAPOL Logoff frames that have been received by this Authenticator.

EapolRespIdFramesRx The number of EAP Resp/Id frames that have been received by this Authenticator.

EapolRespFramesRx The number of valid EAP Response frames (other than Resp/Id frames) that have

been received by this Authenticator.

EapolReqIdFramesTx The number of EAP Req/Id frames that have been transmitted by this Authenticator.

EapolReqFramesTx The number of EAP Request frames (other than Rq/Id frames) that have been

transmitted by this Authenticator.

InvalidEapolFramesRx The number of EAPOL frames that have been received by this Authenticator in which

the frame type is not recognized.

5400_CLI.book Page 504 Wednesday, December 17, 2008 4:33 PM
