Troubleshooting
6-50 Manual # 42-02-7223
Invalid Configuration Inventory Cross Check TALRQ, INV INVTRY XCHK TALRQ
Description: Top Access Landing Rear Qualifier. The safety system detected a configuration/inventory (board
complement) difference when cross checking board complement against system configuration.
Car Reaction: Safety OK remains off.
Troubleshooting:
1. Verify Configuration settings on Setup > Safety > Configuration tab match car options/wiring. Any rear
door options require a rear door board. Likewise, a rear door board requires at least one rear door option
selected on Safety Configuration (Setup > Safety > Configuration tab).
2. If safety configuration is incorrect, make changes and re-learn new configuration using Learn operation
on Setup > Safety > Configuration tab.
3. Re-learn board inventory using Inventory Learn procedure on Setup > Safety > Inventory tab.
4. Reset fault (press iBox FAULT RESET button)
.
Invalid Destination, INVALID DESTINATION
Description: The car has been assigned to a destination floor that does not have an opening.
Car Reaction: Car ignores the demand.
Troubleshooting: Check the current mode of operation and check the corresponding recall floor and verify
that the floor is set to a floor with an opening.
Invalid Front Door Position, INVLD FRONT DOOR PSTN
Description: The front door inputs are in an invalid state (i.e.: doors open and closed at the same time).
Car Reaction: Car is taken out of service and doors will stall.
Troubleshooting:
1. Check all the front door inputs and wiring.
2. Related inputs:
FrontDoorCloseLimit: Low when the doors are fully closed
FrontDoorPositionMonitoring: High when the doors are fully closed
FrontDoorOpenLimit: Low when doors are fully open
FrontCarGate: High when doors are fully closed
Invalid Input (See: Invalid Configuration Input)
Invalid Rear Door Position, INVLD REAR DOOR PSTN
Description: The rear door inputs are in an invalid state (i.e., doors open and closed at the same time).
Car Reaction: Car is taken out of service and doors will stall.
Troubleshooting:
1. Check all the rear door inputs and wiring.
2. Related inputs:
RearDoorCloseLimit: Low when the doors are fully closed
RearDoorPositionMonitoring: High when the doors are fully closed
RearDoorOpenLimit: Low when doors are fully open
RearCarGate: High when doors are fully closed
IO Map Compare Fault, IO MAP COMPARE FAULT
Description: Safety A IO Map did not match Safety B IO Map.
Car Reaction: If running, car makes an emergency stop. Car is not allowed to run.
Troubleshooting:
1. Before the fault has been cleared, you can access additional information about this fault by clicking the
Generate IO Map Fault Report button on the iView > Controller > View > Diagnostics > Data Trap tab
(See “Diagnostics - Data Trap” on page 12.).
2. Press the Fault Reset button to clear the fault.
3. If problem persists it is an indication that the iBox may need to be replaced. Consult MCE Technical Sup-
port for instructions.
Table 6.3 iControl Messages
iControl Messages
