iControl Messages
6-51
6
iControl DC
IO Map Compare Fault Off (See: IO Map Compare Fault)
IO Map Compare Long Term Fault, IO MAP COMPARE LT FLT
Description: Safety A long term products did not match Safety B long term products for 1.2 seconds.
Car Reaction: If running, car makes an emergency stop. Car is not allowed to run.
Troubleshooting:
1. Press the Fault Reset button to clear the fault.
2. If problem persists it is an indication that the iBox may need to be replaced. Consult MCE Technical Sup-
port for instructions.
IO Map Toggle Compare Fault, IO MAP TOGLE COMP FLT
Description: The failure of a safety input was detected during the “input toggle test” (performed at the end of
each run). This test verifies the proper operation of safety system inputs that normally remain unchanged
during the course of elevator operation.
Car Reaction: Emergency stop: Motor contactor and brake contactor immediately dropped.
Troubleshooting:
1. Before the fault has been cleared, you can access additional information about this fault by clicking the
Generate IO Map Fault Report button on the iView > Controller > View > Diagnostics > Data Trap tab
(See “Diagnostics - Data Trap” on page 12.).
2. Press the Fault Reset button to clear the fault.
3. If problem persists it is an indication that the iBox may need to be replaced. Consult MCE Technical Sup-
port for instructions.
IO Map Toggle Compare Fault Off (See: IO Map Toggle Compare Fault)
iView Logged Off. Passenger operation. A previously active iView connection to the controller has logged
off.
iView Logged On. Passenger operation. An iView user has logged on to the controller.
iView Lost Connection. An iView connection has been dropped.
iView Timed Out. An iView connection was inactive for a period of time beyond the idle time out and has
been disconnected.
Jail Master Mode
Description: The car has been placed in Jail Master Mode via the Jail Master Mode Input or via the Jail Oper-
ation PC application.
Car Reaction: The car operates as configured via the Jail > Master mode parameters (See “Jail operation -
Master mode” on page 91.).
Jail Secure Mode
Description: The car has been placed in Jail Secure Mode via the Jail Secure Mode Input or via the Jail Oper-
ation PC application.
Car Reaction: The car operates as configured via the Jail > Secure mode parameters (See “Jail Operation -
Secure mode” on page 94.).
Landing System Sensor Fault, LAND SYS SENSOR FAULT
Description: This fault is generated when a ULM or DLM sensor is activated while the car is running and is
away from a floor. It can also be generated if the M contactor is ON (car is commanded to run) and the safety
system sees a door zone magnet for more than 16 inches of single direction travel.
Car Reaction: Emergency Stop. Motor and brake contactors immediately dropped.
Troubleshooting:
1. Press Fault Reset to clear.
2. If allowed, set Contactor Drop Delay Time to 0.9 seconds.
3. Check for stuck door zone sensor input (front or rear).
Table 6.3 iControl Messages
