iView Windows and Tabs
8-29
8
iControl DC
Virtual
Oscilloscope
An on-board oscilloscope with software selection of test point signals to
be monitored and customizable display (see page 9-22).
Call Generator Use this dialog to generate a new call list (script) or execute an existing
script (see page 9-11).
Table 8.7 Controller - Setup Tabs
Tab Content
Brake Calibrate the brake voltage settings (see page 2-62 and page 9-166).
Counterweight Learn the position where counterweight is adjacent to the car (see page 3-28 and
page 9-167).
Drive Learn the values for the Drive Offsets (see page 2-49 and page 9-168).
Feed Forward Gain Determine a starting value for the Error Compensation parameter on the Configuration
> Drive > Control tab. The objective is to determine the minimum value that should be
used. The optimum value will be between 100% and 150% of calibrated value
(see page 4-16 and page 9-169).
Floor Heights Learn the absolute floor positions (distance to each floor from the lowest landing). Also
used to assist in measuring and entering the floor offsets (deviation of floor magnet
position from actual floor stopping position) (see page 4-2, page 4-28, page 9-170
and page 9-173).
Load Weigher Learn the car empty and full load weights (see page 4-39 and page 9-174).
Motor Field Calibrate the motor field voltages (see page 2-53 and page 9-174).
Safety Verify that the configurations of the main and safety processors match. Perform the
Inventory learn procedure (see page 9-175 and page 9-178).
Synthetic Speed Determine the values for the Voltage safety calibration and Current safety calibration
parameters (Calibration > Drive > Safety tab) which, in conjunction with the Following
error and Tach failure parameters and Speed feedback, are used to determine when a
Tach Failure fault should be generated (see page 4-15 and page 9-179).
Terminal Switches Learn the speeds and positions of the normal and emergency terminal switches (see
page 4-13 and page 9-179).
Table 8.8 Controller - Miscellaneous Dialogs/Controls
Tab Content
Call
Registration
Allows you to register car and hall calls. This control is accessed by clicking the Call
Registration button on the button bar (see page 9-182).
Firmware Update Guides you through the process of updating iControl firmware. This control is accessed
by selecting Firmware Update from the File menu (see page 8-25).
Refresh Updates the information displayed on iView windows and tabs. This control is accessed
by clicking the Refresh button on the button bar.
