Setting Initial Operating Parameters
2-33
2
iControl DC
SYSTEM HUB
LAN HUB
192.168.193.2
255.255.255.0 Subnet Mask
0.0.0.0 ( . . . ) Gateway
PC used for Direct Connection
iCue Group Controller
192.168.191.101
255.255.255.0 Subnet Mask
iView, Direct
PC used for LAN Connection
iView, LAN
ORANGE CABLES
BLUE CABLES
iCue SYSTEM
192.168.192.201
255.255.255.0 Subnet Mask
0.0.0.0 ( . . . ) Gateway
iCue LAN
192.168.191.201
255.255.255.0 Subnet Mask
192.168.191.254 Gateway
Serial
to
Ethernet
Hall
Call
Driver
192.168.192.214
