iView - Controller View
9-172 Manual # 42-02-7223
Learn The following controls and messages pertain to the Floor Heights Learn procedure.
Follow the instructions displayed in the message window to perform the learn procedure.
• Type - Manual / Auto. On Manual, you use the iBox Enable and Up/Down switches to run
the car through the hoistway. On Auto, iControl will run the car through the hoistway
automatically.
• Status - The following status messages can be displayed:
• Waiting for learn request: Waiting for the Learn button to be clicked.
• Waiting for proper start location: The car must be moved onto the down directional
limit before the learn operation can begin.
• Idle: The elevator is at the proper start location and the learn procedure is activated.
• Acquiring floor markers: The learn operation is In progress. The car is moving
through the hoistway capturing the location of the floor magnets.
• Invalid floor sensor transition: The system expects the ULM, DZ and DLM sensors to
activate and deactivate in the proper sequence as the elevator passes a landing magnet
or vane. A floor sensor transition other than the expected transition has occurred. This
can occur when a floor sensor and magnet are misaligned, the floor sensor and magnet
are not in the correct proximity (distance) or the sensor has malfunctioned. (For a
NEMA or slide-guide iLand, this can occur when the sensor and a floor vane are not
correctly aligned or adjusted. The vanes must be exactly perpendicular to the sensor).
• Acquired floor markers fewer than configuration: The number of floor magnets sensed
during the learn operation is less than the number of floors and false floors indicated
on the Controller view > Configuration > General > Floor Data tab.
• Acquired floor markers more than configuration: The number of floor magnets sensed
during the learn operation is greater than the number of floors and false floors indi-
cated on the Controller view > Configuration > General > Floor Data tab.
• Configured floor markers more than maximum allowed: The number of floor magnets
sensed during the learn operation is more than the maximum number supported.
• Acquired floor marker heights mismatch configuration: The height and/or location of
the detected floor magnets does not match the configuration (Controller > Configura-
tion > General > Floor data tab) in one of the following ways:
• the sequence of the front and rear magnets does not match the configuration,
• the floor magnets for a walk-through floor are greater than one inch apart,
• the floor magnets for two non-walk-through floors is less than one inch apart.
• Learned: The Floor Heights Learn operation has been completed.
• Saved: The floor heights have been saved on the controller’s iBox.
• Learn button: When the Ready status light is on, the Learn button starts the Floor Heights
Learn procedure and the In progress status light turns on.
• Abort button: The Floor Heights Learn procedure may be halted by clicking the Abort but-
ton. If the learn procedure is aborted, the last saved complete set of floor height values is
retained.
When the Done status light turns on, the iBox Learn switch may be set to the OFF position.
Click the Refresh button ( ) to update the learned floor height information on the Controller
view > Configuration > Floor Heights > Configurations tab.
