MCE iControl User Manual

Quattro DC Drive Parameters Quick Reference
11-29
11
iControl DC
A2 ACCEL JERK IN 3
ft/s3
0.0 – 29.9 8.0
8.0
m/s3
0.00 – 9.99 2.40
A2 ACCEL JERK OUT 3
ft/s3
0.0 – 29.9 8.0
8.0
m/s3
0.00 – 9.99 2.40
A2 DECEL JERK IN 3
ft/s3
0.0 – 29.9 8.0
8.0
m/s3
0.00 – 9.99 2.40
A2 DECEL JERK OUT 3
ft/s3
0.0 – 29.9 8.0
8.0
Menu
Parameter
Units
Range Default Factory Setting
A3
Multistep Ref A3 Submenu
A3 SPEED COMMAND 1
ft/min -3000.0 – +3000.0 0.0
0.0
m/sec -16.000 – +16.000 0.000
A3 SPEED COMMAND 2
ft/min -3000.0 – +3000.0 0.0
0.0
m/sec -16.000 – +16.000 0.000
A3 SPEED COMMAND 3
ft/min -3000.0 – +3000.0 0.0
0.0
m/sec -16.000 – +16.000 0.000
A3 SPEED COMMAND 4
ft/min -3000.0 – +3000.0 0.0
0.0
m/sec -16.000 – +16.000 0.000
A3 SPEED COMMAND 5
ft/min -3000.0 – +3000.0 0.0
0.0
m/sec -16.000 – +16.000 0.000
A3 SPEED COMMAND 6
ft/min -3000.0 – +3000.0 0.0
0.0
m/sec -16.000 – +16.000 0.000
A3 SPEED COMMAND 7
ft/min -3000.0 – +3000.0 0.0
0.0
m/sec -16.000 – +16.000 0.000
A3 SPEED COMMAND 8
ft/min -3000.0 – +3000.0 0.0
0.0
m/sec -16.000 – +16.000 0.000
A3 SPEED COMMAND 9
ft/min -3000.0 – +3000.0 0.0
0.0
m/sec -16.000 – +16.000 0.000
A3 SPEED COMMAND 10
ft/min -3000.0 – +3000.0 0.0
0.0
m/sec -16.000 – +16.000 0.000
A3 SPEED COMMAND 11
ft/min -3000.0 – +3000.0 0.0
0.0
m/sec -16.000 – +16.000 0.000
A3 SPEED COMMAND 12
ft/min -3000.0 – +3000.0 0.0
0.0
m/sec -16.000 – +16.000 0.000
A3 SPEED COMMAND 13
ft/min -3000.0 – +3000.0 0.0
0.0
m/sec -16.000 – +16.000 0.000
