MCE iControl User Manual

Reference
11-30 Manual # 42-02-7223
A3 SPEED COMMAND 14
ft/min -3000.0 – +3000.0 0.0
0.0
m/sec -16.000 – +16.000 0.000
A3 SPEED COMMAND 15
ft/min -3000.0 – +3000.0 0.0
0.0
m/sec -16.000 – +16.000 0.000
Menu
Parameter
Units
Range Default Factory Setting
A4
Motor Side Power Convert A4 Submenu
A4 ARM INDUCTANCE mH 0.01 – 327.67 15.00
129.21
A4 ARM RESISTANCE ohm 0.0001 – 2.9999 0.5000
2.5444
A4 MTR REV VLT LIM % 0.01 – 30.00 12.00
2606
A4 MOTOR FIELD RES ohm 0.0 – 3276.7 9.0
A4 MOTOR FIELD TC sec 0.000 – 32.767 0.607
A4 AUTO TUNE MOTOR none − Start Autotune? -
A4 GAIN SELECTION none
− manual − use
saved par − use
self tune
MANUAL
USE SELF
TUNE
A4 GAIN BANDWIDTH A rad/sec 100 – 2000 500
500
A4 GAIN BANDWIDTH F rad/sec 1 – 40 5
5
A4 SPD MODEFILT BW rad/sec 5 – 110 100
100
A4 PWM FREQUENCY kHz 2.5 – 16.0 6.0
6
A4 FAN OFF DELAY sec 0 – 999 180
180
A4 MAIN FAN CONTROL none
− time −
temperature
TEMPERATURE
TEMPERATURE
A4 UV ALARM LEVEL % 80 – 99 90
90
A4 UV FAULT LEVEL % 50 – 99 80
80
A4 FLD CARRIER FRQ kHz 3 – 40 3
3
A5 Line Side Power converter A5 Submenu
A5 Id REG PROP GAIN none 0.00 – 9.99 0.30
0.30
A5 Id REG INTGRL GAIN none 0 – 999 10
10
A5 Iq REG PROP GAIN none 0.00 – 9.99 0.30
0.30
A5 Iq REG INTGRL GAIN none 0 – 999 40
40
A5 DC BUS REG P GAIN none 0.00 – 9.99 3.00
3.00
A5 DC BUS REG I GAIN none 0 – 999 40
40
A5 INPUT L-L VOLTS volts 150 – 552 200
480
A5 INITIAL L FREQ Hz 50 – 60 55
A5 DC BUS V BOOST volts 15 – 75 30
30
A5 SW BUS OV LEVEL volts 100 – 850 850
850
A5 BUS VREF SOURCE none
− track line v − trk
vin param
TRACK LINE V
TRACK LINE V
A5 PLL FILTER FC Hz 20.0 – 150.0 40.0
40.0
A5 POLE FILTER kHz 0.0 – 3.0 2.2
A5 PRE CHGE THRESH none 1 – 60 28
28
A5 LS PWM FREQUENCY kHz 8.0 – 12.0 10.0
10.0
