MCE iControl User Manual

Quattro DC Drive Parameters Quick Reference
11-31
11
iControl DC
Menu
Parameter
Units
Range Default Factory Setting
A6
Motor A6 Submenu
A6 MOTOR ID none - -
A6 RATED MOTOR CURR amps 1.0 – 400.0 0.0 53
A6 ARMATURE VOLTAGE volts 55 – 600 0 375
A6 FULL FLD CURRENT amps 1.0 – 40.0 0.0 13.0
A6 WEAK FLD CURRENT amps 1.0 – 40.0 0.0 10.4
A6 STANDBY FIELD amps 0.0 – 40.0 0.0 3.0
A6 FLUX CONFIRM LEV % 25.0 – 99.0 85.0 55.0
A6 ARMATURE IR DROP % 0.0 – 25.0 0.0 6.0
A6 TACH VOLT SENSE % 0.1 – 60.0 25.0 25.0
A6 TACH SPEED SENSE % 0.1 – 40.0 5.0 5.0
A6 OVLD START LEVEL % 100 – 150 110 110
A6 OVLD TIME OUT sec 5.0 – 120.0 60.0 60.0
A6 SAVE MEAS ARM L mH 0.00 – 327.67 0.00 121.6
A6 SAVE IR DROP % 0.0 – 3276.7 0.0 35.2
A6 SAVE MEAS ARM R ohm 0.0000 – 3.2767 0.0000 2.5029
A6 SAVE FIELD RES ohm 0.0 – 3276.7 0.00 13.2
A6 SAVE FIELD TC sec 0.000 – 32.767 0.000 0.440
C1 User Switches C1 Submenu
C1 SPD COMMAND SRC none
− serial
− multi-step
− ser mult step
− analog input
MULTI-STEP ANALOG INPUT
C1 RUN COMMAND SRC none
− external tb
− serial
− serial+extrn
EXTERNAL TB EXTERNAL TB
C1 FIELD ENA SOURCE none
− external tb
− serial
− enable on run
− 2-bit serial
ENABLE ON
RUN
ENABLE ON RUN
C1 HI/LO GAIN SRC none
− internal
− external tb
− serial
INTERNAL INTERNAL
C1 SPEED REG TYPE none
− elev spd reg
− pi speed reg
− external reg
− cemf reg
ELEV SPD REG ELEV SPD REG
C1 MOTOR ROTATION none
− forward
− reverse
FORWARD FORWARD
C1 ENCODER CONNECT none
− forward
− reverse
FORWARD FORWARD
C1 SPD REF RELEASE none
− reg release
− brake picked
REG RELEASE REG RELEASE
C1 CONT CONFIRM SRC none
− external tb
− none
NONE NONE
C1 TACH FILTER none
− off
− on
OFF OFF
C1 PreTorque SOURCE none
− none
− analog input
− serial
NONE NONE
C1 PreTorque LATCH none
− latched
− not latched
NOT LATCHED NOT LATCHED
C1 PTorq LATCH CLCK none
− external tb
− seria
EXTERNAL TB EXTERNAL TB
