Quattro DC Drive Parameters Quick Reference
11-33
11
iControl DC
Menu
Parameter Units Range Default
Factory Setting
C3 Logic Outputs C3 Submenu
C3
LOGIC OUTPUT 1
TB1(25)
− alarm
− alarm+flt
− auto brake
− brake hold
− brake pick
− brk hold flt
− brk pick flt
− car going dwn
− car going up
− charge fault
− close contact
− contactor flt
− curr reg flt
− drv overload
− encoder flt
− fault
− flux confirm
− ground fault
− in low gain
− motor trq lim
− mtr overload
− no faults
− no function
− not alarm
− over curr flt
− overspeed flt
− overtemp flt
− overvolt flt
− ovrtemp alarm
− phase fault
− ramp down ena
− ready 2 start
− ready to run
− regen trq lim
− run commanded
− run confirm
− speed dev
− speed dev low
− speed ref rls
− speed reg rls
− undervolt flt
− up to speed
− uv alarm
− zero
speed
CLOSE
CONTACT
CLOSE CONTACT
C3
LOGIC OUTPUT 2
TB1(26)
RUN
COMMANDED
RUN COMMAND
C3
LOGIC OUTPUT 3
TB1(27)
MTR
OVERLOAD
MTR OVERLOAD
C3
LOGIC OUTPUT 4
TB1(28)
ENCODER FLT
ENCODER FLT
C3
LOGIC OUTPUT 5
TB1(29)
FAULT
FAULT
C3
LOGIC OUTPUT 6
TB1(30)
SPEED REG
RLS
SPEED REG RLS
C3
LOGIC OUTPUT 7
TB1(31)
SPEED REG
RLS
SPEED REG RLS
C3 SSR1 TB1(21/22) NO FUNCTION
READY TO RUN
C3 SSR2 TB1(23/24) NO FUNCTION
SPEED REG RLS
C3
RELAY COIL 1 TB2 (1/
3/5)
NO FUNCTION
READ 2 START
C3
RELAY COIL 2 TB2 (8/
10/12)
NO FUNCTION
FLUX CONFIRM
C4 Analog Outputs C4 Submenu – See Analog Outputs C4 submenu on page 70
C4 ANA OUT 1 TB1-12
− analog addr2
− analog addr3
− arm current
− arm voltage
− aux torq cmd
− bus voltage
− est motor spd
− field current
− iarm error
− ls pwr input
− pretorque ref
− motor mode
− spd rg tq cmd
− speed command
− speed error
− speed feedbk
− speed ref
− tach rate cmd
− tach speed
− torque ref
SPEED REF
SPEED REF
C4 ANA OUT 2 TB1-13
SPEED
FEEDBK
SPEED FEEDBK
To Next Page
