SINAMICS DCP
List Manual (LH21), 05/2016
101
2 Parameters
2.2 List of parameters
External fault 3 is initiated by the following AND logic operation:
- BI: p2108 negated
- BI: p3111
- BI: p3112 negated
Dependency: Refer to: p3110, p3111, p3112
Refer to: F07862
Note: An external fault is triggered with a 1/0 signal.
If this fault is output at the Control Unit, then it is transferred to all existing drive objects.
Description: Displays the system runtime in milliseconds when the fault was removed.
Dependency: Refer to: r0945, r0947, r0948, r0949, r2114, r2130, r2133, r2136, r3115, r3120, r3122
Notice: The time comprises r2136 (days) and r2109 (milliseconds).
Note: The buffer parameters are cyclically updated in the background (refer to status signal in r2139).
The structure of the fault buffer and the assignment of the indices is shown in r0945.
Description: Displays the system runtime in milliseconds when the fault was removed.
Dependency: Refer to: r0945, r0947, r0948, r0949, r2114, r2130, r2133, r2136, r3115, r3120, r3122
Notice: The time comprises r2136 (days) and r2109 (milliseconds).
Note: The buffer parameters are cyclically updated in the background (refer to status signal in r2139).
The structure of the fault buffer and the assignment of the indices is shown in r0945.
Description: This parameter is identical to r2122.
Description: Number of alarms that have occurred after the last reset.
Dependency: When p2111 is set to 0, the following is initiated:
- all of the alarms of the alarm buffer that have gone [0...7] are transferred into the alarm history [8...63].
- the alarm buffer [0...7] is deleted.
Refer to: r2110, r2122, r2123, r2124, r2125
Note: The parameter is reset to 0 at POWER ON.
r2109[0...63] Fault time removed in milliseconds / t_flt resolved ms
CU_DCP, TM150,
TM15DI_DO, TM31
Can be changed: - Access level: 3
Data type: Unsigned32 Func. diagram: 8050, 8060
Min Max Factory setting
- [ms] - [ms] - [ms]
r2109[0...63] Fault time removed in milliseconds / t_flt resolved ms
DCP_CTRL Can be changed: - Access level: 3
Data type: Unsigned32 Func. diagram: 8060
Min Max Factory setting
- [ms] - [ms] - [ms]
r2110[0...63] Alarm number / Alarm number
All objects Can be changed: - Access level: 2
Data type: Unsigned16 Func. diagram: 8065
Min Max Factory setting
- - -
p2111 Alarm counter / Alarm counter
CU_DCP, DCP_CTRL Can be changed: U, T Access level: 3
Data type: Unsigned16 Func. diagram: 8065
Min Max Factory setting
0 65535 0
