SINAMICS DCP
List Manual (LH21), 05/2016
239
2 Parameters
2.2 List of parameters
Description: Display and connector output for the sequence control operating state.
SINAMICS DCP is presently being operated in these quadrants.
Note: Value: significance (quadrant)
0: pulse inhibit
1: step-down, positive current
2: step-up, positive current
-1: step-down, negative current
-2: step-up, negative current
Description: Displays more detailed information about faults which have occurred with numbers 60000 and higher.
[0] = Fault value
[1] = Additional information about the most recent fault which occurred (see corresponding fault)
...
[30] = Additional information about the most recent fault which occurred (see corresponding fault)
[31] = Fault number
Description: Displays the existing software versions.
Index: [0] = Complete device version external
[1] = Complete device version internal
[2] = DSAC bootloader version
[3] = BIOS version
[4] = Configuration EEPROM version
[5] = Base system version
[6] = DC/DC converter version
[7] = TMS version
[8] = TMS image version
[9] = TMS bootloader version
[10] = TMS bootloader image version
[11] = Mainboard version
[12] = Mainboard bootloader version
[13] = DCC version
[14] = FBLOCKS version
Note: Some of these software versions are also displayed using the following parameters.
Index 0 <--> r7844[1]
Index 1 <--> r7844[0]
Index 2 <--> r0197
Index 5 <--> r0018
Index 6, 13, 14 <--> r4957[x]
r50001 CO: Sequence control quadrant display / Seq_ctrl quad_dis
DCP_CTRL Can be changed: - Access level: 2
Data type: Integer32 Func. diagram: 2650, 6830
Min Max Factory setting
- - -
r50047[0...31] Faults additional information / Fault add info
DCP_CTRL Can be changed: - Access level: 2
Data type: FloatingPoint32 Func. diagram: 2650
Min Max Factory setting
- - -
r50060[0...14] Software version / SW version
DCP_CTRL Can be changed: - Access level: 1
Data type: Unsigned32 Func. diagram: 8054
Min Max Factory setting
- - -
