2 Parameters
2.2 List of parameters
SINAMICS DCP
98 List Manual (LH21), 05/2016
Notice: For the following cases, it is not possible to re-parameterize the fault response to a fault:
- Fault number does not exist (exception value = 0).
- Message type is not "fault" (F).
- Fault response is not permissible for the set fault number.
Note: Re-parameterization is also possible if a fault is present. The change only becomes effective after the fault has been
resolved.
The fault response can only be changed for faults with the appropriate identification (see the List Manual, chapter
"Faults and alarms").
Example:
F12345 and fault response = OFF3 (OFF1, OFF2, NONE)
--> The default fault response OFF3 can be changed to OFF1, OFF2 or NONE.
Re value = 1 (OFF1):
Braking along the ramp-function generator down ramp followed by a pulse inhibit.
Re value = 2 (OFF2):
Internal/external pulse inhibit.
Re value = 3 (OFF3):
Braking along the OFF3 down ramp followed by a pulse inhibit.
Parameter values designated as "reserved", act just like the value = 2 (OFF2)
Description: Sets the fault response for the selected fault.
Value: 0: NONE
Dependency: The fault is selected and the required response is set under the same index.
Notice: For the following cases, it is not possible to re-parameterize the fault response to a fault:
- Fault number does not exist (exception value = 0).
- Message type is not "fault" (F).
- Fault response is not permissible for the set fault number.
Note: Re-parameterization is also possible if a fault is present. The change only becomes effective after the fault has been
resolved.
Description: Sets the signal source to acknowledge all faults at all drive objects of the drive system.
Note: A fault acknowledgement is triggered with a 0/1 signal.
Description: Sets the first signal source to acknowledge faults.
Notice: The parameter may be protected as a result of p0922 or p2079 and cannot be changed.
Note: A fault acknowledgement is triggered with a 0/1 signal.
p2101[0...19] Change fault response response / Chng resp resp
TM150, TM15DI_DO,
TM31
Can be changed: U, T Access level: 3
Data type: Integer16 Func. diagram: 8050, 8075
Min Max Factory setting
0 0 0
p2102 BI: Acknowledge all faults / Ackn all faults
CU_DCP Can be changed: U, T Access level: 3
Data type: Unsigned32 / Binary Func. diagram: 2546, 8060
Min Max Factory setting
- - 0
p2103 BI: 1. Acknowledge faults / 1. Acknowledge
CU_DCP, TM150,
TM15DI_DO, TM31
Can be changed: U, T Access level: 3
Data type: Unsigned32 / Binary Func. diagram: -
Min Max Factory setting
- - 0
