2 Parameters
2.2 List of parameters
SINAMICS DCP
78 List Manual (LH21), 05/2016
[46] = PZD 47 + 48
[47] = PZD 48 + 49
[48] = PZD 49 + 50
[49] = PZD 50 + 51
[50] = PZD 51 + 52
[51] = PZD 52 + 53
[52] = PZD 53 + 54
[53] = PZD 54 + 55
[54] = PZD 55 + 56
[55] = PZD 56 + 57
[56] = PZD 57 + 58
[57] = PZD 58 + 59
[58] = PZD 59 + 60
[59] = PZD 60 + 61
[60] = PZD 61 + 62
[61] = PZD 62 + 63
[62] = PZD 63 + 64
Notice: A maximum of 4 indices of the "trace" function can be used.
Note: IF1: Interface 1
Description: Displays the last parameter received from the PROFIBUS/PROFINET controller for clock synchronism.
The parameters for clock synchronism are created when configuring the bus and are transferred at the start of cyclic
operation from the controller to the device.
Bit field: Bit Signal name 1 signal 0 signal FP
00 Bit 0 ON OFF -
01 Bit 1 ON OFF -
02 Bit 2 ON OFF -
03 Bit 3 ON OFF -
04 Bit 4 ON OFF -
05 Bit 5 ON OFF -
06 Bit 6 ON OFF -
07 Bit 7 ON OFF -
08 Bit 8 ON OFF -
09 Bit 9 ON OFF -
10 Bit 10 ON OFF -
11 Bit 11 ON OFF -
12 Bit 12 ON OFF -
13 Bit 13 ON OFF -
14 Bit 14 ON OFF -
15 Bit 15 ON OFF -
16 Bit 16 ON OFF -
17 Bit 17 ON OFF -
18 Bit 18 ON OFF -
19 Bit 19 ON OFF -
20 Bit 20 ON OFF -
21 Bit 21 ON OFF -
22 Bit 22 ON OFF -
23 Bit 23 ON OFF -
24 Bit 24 ON OFF -
25 Bit 25 ON OFF -
26 Bit 26 ON OFF -
27 Bit 27 ON OFF -
28 Bit 28 ON OFF -
29 Bit 29 ON OFF -
30 Bit 30 ON OFF -
31 Bit 31 ON OFF -
r2064[0...7] PB/PN diagnostics clock cycle synchronism / PB/PN diag clock
CU_DCP Can be changed: - Access level: 3
Data type: Integer32 Func. diagram: -
Min Max Factory setting
- - -
