2 Parameters
2.2 List of parameters
SINAMICS DCP
220 List Manual (LH21), 05/2016
Description: Displays the controller assignment of a PROFINET subslot on the actual drive object.
Index: [0] = Subslot 2 PROFIsafe
[1] = Subslot 3 PZD telegram
[2] = Subslot 4 PZD supplementary data
Note: Example:
If the parameter contains the value 2 in index [1], then this means that subslot 3 is assigned to controller 2.
Description: Displays the controller assignment of a PROFINET subslot on the actual drive object.
Index: [0] = Subslot 2 PROFIsafe
[1] = Subslot 3 PZD telegram
[2] = Subslot 4 PZD supplementary data
Dependency: Refer to: r8971, r8972
Note: Example:
If the parameter contains the value 2 in index [1], then this means that subslot 3 is assigned to controller 2.
Description: Displays the IP address of the first PROFINET controller connected with the device via CBE20/CBE25.
Description: Displays the IP address of the second PROFINET controller connected with the device via CBE20/CBE25.
Description: Data setting to read topology properties.
The result is displayed depending on the property in r9207 or r9208.
Re index 0:
0: actual topology, 1: target topology
Re index 1:
Sets the component number of the component involved.
r8960[0...2] PN subslot controller assignment / PN subslot assign
All objects Can be changed: - Access level: 3
Data type: Unsigned8 Func. diagram: -
Min Max Factory setting
0 8 -
r8970[0...2] CBE2x subslot controller assignment / CBE2x subslot
CU_DCP (PROFINET
CBE20), DCP_CTRL
(PROFINET CBE20),
TM150 (PROFINET
CBE20), TM15DI_DO
(PROFINET CBE20),
TM31 (PROFINET
CBE20)
Can be changed: - Access level: 3
Data type: Unsigned8 Func. diagram: -
Min Max Factory setting
0 8 -
r8971[0...3] CBE2x IP Address Remote Controller 1 / CBE2x IP Rem Ctrl1
CU_DCP (PROFINET
CBE20)
Can be changed: - Access level: 3
Data type: Unsigned8 Func. diagram: -
Min Max Factory setting
0 255 -
r8972[0...3] CBE2x IP Address Remote Controller 2 / CBE2x IP Rem Ctrl2
CU_DCP (PROFINET
CBE20)
Can be changed: - Access level: 3
Data type: Unsigned8 Func. diagram: -
Min Max Factory setting
0 255 -
p9206[0...2] Topology direct access / Topo access
CU_DCP Can be changed: T Access level: 3
Data type: Unsigned32 Func. diagram: -
Min Max Factory setting
0 4294967295 0
