SINAMICS DCP
List Manual (LH21), 05/2016
91
2 Parameters
2.2 List of parameters
Description: Binector output for bit-serial interconnection of PZD2 received from the PROFIdrive controller.
Note: IF1: Interface 1
Description: Binector output for bit-serial interconnection of PZD2 received from the PROFIdrive controller.
Note: IF1: Interface 1
Description: Binector output for bit-serial interconnection of PZD3 received from the PROFIdrive controller.
r2091.0...15 BO: IF1 PROFIdrive PZD2 receive bit-serial / IF1PZD2recvbitw
CU_DCP, DCP_CTRL Can be changed: - Access level: 3
Data type: Unsigned16 Func. diagram: 2460, 2481
Min Max Factory setting
- - -
Bit field: Bit Signal name 1 signal 0 signal FP
00 Bit 0 ON OFF -
01 Bit 1 ON OFF -
02 Bit 2 ON OFF -
03 Bit 3 ON OFF -
04 Bit 4 ON OFF -
05 Bit 5 ON OFF -
06 Bit 6 ON OFF -
07 Bit 7 ON OFF -
08 Bit 8 ON OFF -
09 Bit 9 ON OFF -
10 Bit 10 ON OFF -
11 Bit 11 ON OFF -
12 Bit 12 ON OFF -
13 Bit 13 ON OFF -
14 Bit 14 ON OFF -
15 Bit 15 ON OFF -
r2091.0...15 BO: IF1 PROFIdrive PZD2 receive bit-serial / IF1PZD2recvbitw
TM150, TM15DI_DO,
TM31
Can be changed: - Access level: 3
Data type: Unsigned16 Func. diagram: 2468
Min Max Factory setting
- - -
Bit field: Bit Signal name 1 signal 0 signal FP
00 Bit 0 ON OFF -
01 Bit 1 ON OFF -
02 Bit 2 ON OFF -
03 Bit 3 ON OFF -
04 Bit 4 ON OFF -
05 Bit 5 ON OFF -
06 Bit 6 ON OFF -
07 Bit 7 ON OFF -
08 Bit 8 ON OFF -
09 Bit 9 ON OFF -
10 Bit 10 ON OFF -
11 Bit 11 ON OFF -
12 Bit 12 ON OFF -
13 Bit 13 ON OFF -
14 Bit 14 ON OFF -
15 Bit 15 ON OFF -
r2092.0...15 BO: IF1 PROFIdrive PZD3 receive bit-serial / IF1PZD3recvbitw
CU_DCP Can be changed: - Access level: 3
Data type: Unsigned16 Func. diagram: 2468
Min Max Factory setting
- - -
