SINAMICS DCP
List Manual (LH21), 05/2016
267
2 Parameters
2.2 List of parameters
Description: Display and connector output for the conversion result at analog input 6 (X177.7/8) on the CUD.
Note: AI: Analog Input
Description: Display and connector output for analog output 0 (X177.49/50) of the CUD.
Dependency: Refer to: p50750
Note: AO: Analog Output
Description: Display and connector output for analog output 1 (X177.51/52) of the CUD.
Dependency: Refer to: p50755
Note: AO: Analog Output
Description: Display and connector output for the device's temperature outputs.
Index: [0] = Temperature power unit 1
[1] = Temperature power unit 2
[2] = Power supply temperature
[3] = Mainboard temperature
[4] = CUD Control Unit temperature
[5] = Air intake temperature
[6] = Temperature power unit 3
Description: Display and connector output for the power unit temperatures of the device.
Index: [0] = Temperature power unit 1
[1] = Temperature power unit 2
[2] = Temperature power unit 3
r52025 CO: CUD analog input 6 result / CUD AI 6 res
DCP_CTRL Can be changed: - Access level: 3
Data type: FloatingPoint32 Func. diagram: 2090
Min Max Factory setting
- [%] - [%] - [%]
r52026 CO: CUD analog output 0 value after smoothing / CUD AO 0 val af sm
DCP_CTRL Can be changed: - Access level: 3
Data type: FloatingPoint32 Func. diagram: 2095
Min Max Factory setting
- [%] - [%] - [%]
r52027 CO: CUD analog output 1 value after smoothing / CUD AO 1 val af sm
DCP_CTRL Can be changed: - Access level: 3
Data type: FloatingPoint32 Func. diagram: 2095
Min Max Factory setting
- [%] - [%] - [%]
r52050[0...6] CO: Temperature sensor display / Temp sensor disp
DCP_CTRL Can be changed: - Access level: 2
Data type: FloatingPoint32 Func. diagram: 8048
Min Max Factory setting
- [°C] - [°C] - [°C]
r52051[0...2] CO: Temperature sensor power unit display / Temp_sens PU_dis
DCP_CTRL Can be changed: - Access level: 2
Data type: FloatingPoint32 Func. diagram: 8048
Min Max Factory setting
- [°C] - [°C] - [°C]
