SINAMICS DCP
List Manual (LH21), 05/2016
183
2 Parameters
2.2 List of parameters
Description: Displays the GUIDs of the OA applications installed on this drive object.
r4959[0...15]: GUID of OA application 1
r4959[16]: Major information of OA application 1
r4959[17]: Minor information of OA application 1
r4959[18...33]: GUID of OA application 2
r4959[34]: Major information of OA application 2
r4959[35]: Minor information of OA application 2, ...
Dependency: Refer to: r4950, r4951, r4952, r4955, p4956, r4957, r4958, r4960
Notice: If there is no OA application, then it is not possible to access an index.
Description: Displays the GUIDs of this drive object of the OA applications installed on the memory card/device memory.
r4960[0...15]: GUID of this drive object of OA application 1
r4960[16]: Major information of this drive object of OA application 1
r4960[17]: Minor information of this drive object of OA application 1
r4960[18...33]: GUID of this drive object of OA application 2
r4960[34]: Major information of this drive object of OA application 2
r4960[35]: Minor information of this drive object of OA application 2, ...
Dependency: Refer to: r4950, r4951, r4952, r4955, p4956, r4957, r4958, r4959
Notice: If there is no OA application, then it is not possible to access an index.
Description: Only for service purposes.
Description: Displays the number of OA applications installed on the memory card/device memory.
Dependency: Refer to: r4986, r4987, r4988, r4989, r4990, r4991, r4992, r4993, r4994
Note: OA: Open Architecture (OA application)
Description: Displays the total length of the IDs of all the OA applications installed on the memory card/device memory.
r4959[0...n] OA DO-specific GUID / OA DO GUID
CU_DCP, TM150,
TM15DI_DO, TM31
Can be changed: - Access level: 4
Data type: Unsigned8 Func. diagram: -
Min Max Factory setting
- - -
r4960[0...n] OA DO-specific GUID drive object / OA DO GUID DO
CU_DCP, TM150,
TM15DI_DO, TM31
Can be changed: - Access level: 4
Data type: Unsigned8 Func. diagram: -
Min Max Factory setting
- - -
p4961[0...n] OA DO-specific logbook module selection / OA DO log module
CU_DCP, TM150,
TM15DI_DO, TM31
Can be changed: T Access level: 4
Data type: Unsigned32 Func. diagram: -
Min Max Factory setting
0000 hex FFFF FFFF hex 0000 hex
r4985 OA number / OA no
CU_DCP Can be changed: - Access level: 4
Data type: Unsigned16 Func. diagram: -
Min Max Factory setting
0 16 -
r4986 OA identifier total length / OA id tot_length
CU_DCP Can be changed: - Access level: 4
Data type: Unsigned16 Func. diagram: -
Min Max Factory setting
0 144 -
