Siemens sinamics dcp - p50725 CUD analog input 2 smoothing time constant; CUD AI 2 T; p50726 BI: CUD analog input 2 signal source for enable; CUD AI 2 ena s_src; p50731[0...3] Fast analog inputs scaling; Fast AI scal; p50732[0...3] Fast analog inputs offset; Fast AI offs

2 Parameters
2.2 List of parameters
SINAMICS DCP
248 List Manual (LH21), 05/2016
Description: Sets the time constant for smoothing the signal from analog input 2 (AI 2, X177.29/30) on the CUD.
Note: AI: Analog Input
Description: Sets the signal source to enable analog input 2 (AI 2, X177.29/30) on the CUD.
Note: AI: Analog Input
Description: Sets the scaling for fast analog inputs "Select input 3 ... 6".
The value indicates the percentage value for mapping an input voltage of 10 V at the analog input.
Example:
p50731[2] = 90%
--> 10 V is scaled to 90% for select input 5
--> 5 V corresponds to 45% for select input 5
Index: [0] = Select input 3 (X177.1/2)
[1] = Select input 4 (X177.3/4)
[2] = Select input 5 (X177.5/6)
[3] = Select input 6 (X177.7/8)
Note: AI: Analog Input
Description: Sets the offset for fast analog inputs "Select input 3 ... 6".
Index: [0] = Select input 3 (X177.1/2)
[1] = Select input 4 (X177.3/4)
[2] = Select input 5 (X177.5/6)
[3] = Select input 6 (X177.7/8)
Note: AI: Analog Input
Description: Sets the signal processing for fast analog inputs "Select input 3 ... 6".
p50725 CUD analog input 2 smoothing time constant / CUD AI 2 T
DCP_CTRL Can be changed: U, T Access level: 3
Data type: FloatingPoint32 Func. diagram: 2080
Min Max Factory setting
0 [ms] 10000 [ms] 0 [ms]
p50726 BI: CUD analog input 2 signal source for enable / CUD AI 2 ena s_src
DCP_CTRL Can be changed: T Access level: 3
Data type: Unsigned32 / Binary Func. diagram: 2080
Min Max Factory setting
- - 1
p50731[0...3] Fast analog inputs scaling / Fast AI scal
DCP_CTRL Can be changed: U, T Access level: 3
Data type: FloatingPoint32 Func. diagram: 2085, 2090
Min Max Factory setting
-1000.0 [%] 1000.0 [%] 100.0 [%]
p50732[0...3] Fast analog inputs offset / Fast AI offs
DCP_CTRL Can be changed: U, T Access level: 3
Data type: FloatingPoint32 Func. diagram: 2085, 2090
Min Max Factory setting
-200.00 [%] 200.00 [%] 0.00 [%]
p50733[0...3] Fast analog inputs signal processing / Fast AI sig
DCP_CTRL Can be changed: T Access level: 3
Data type: Integer16 Func. diagram: 2085, 2090
Min Max Factory setting
0 3 0
