SINAMICS DCP
List Manual (LH21), 05/2016
253
2 Parameters
2.2 List of parameters
Dependency: Refer to: r53010
Note: DI: Digital Input
Description: Sets the delay time for digital input 2 (DI 2, X177.13) on the CUD.
Dependency: Refer to: r53010
Note: DI: Digital Input
Description: Sets the delay time for digital input 3 (DI 3, X177.14) on the CUD.
Dependency: Refer to: r53010
Note: DI: Digital Input
Description: Setting to invert the signal from digital output 0 ... 3 (DO 0 ... DO 3) of the CUD.
Value: 0: Not inverted
1: Inverted
Index: [0] = DO 0 (X177.19)
[1] = DO 1 (X177.20)
[2] = DO 2 (X177.21)
[3] = DO 3 (X177.22)
Note: DO: Digital Output
Description: Sets the signal source for digital output 0 (DO 0, X177.19) on the CUD.
Note: DO: Digital Output
Description: Sets the signal source for digital output 1 (DO 1, X177.20) on the CUD.
Note: DO: Digital Output
p50767 CUD digital input 2 delay time / CUD DI 2 t_del
DCP_CTRL Can be changed: U, T Access level: 3
Data type: FloatingPoint32 Func. diagram: 2050
Min Max Factory setting
0 [ms] 10000 [ms] 0 [ms]
p50768 CUD digital input 3 delay time / CUD DI 3 t_del
DCP_CTRL Can be changed: U, T Access level: 3
Data type: FloatingPoint32 Func. diagram: 2050
Min Max Factory setting
0 [ms] 10000 [ms] 50 [ms]
p50770[0...3] CUD digital outputs inversion / CUD DO inv
DCP_CTRL Can be changed: U, T Access level: 3
Data type: Integer16 Func. diagram: 2055
Min Max Factory setting
0 1 0
p50771 BI: CUD digital output 0 signal source / CUD DO 0 s_src
DCP_CTRL Can be changed: U, T Access level: 3
Data type: Unsigned32 / Binary Func. diagram: 2055
Min Max Factory setting
- - 0
p50772 BI: CUD digital output 1 signal source / CUD DO 1 s_src
DCP_CTRL Can be changed: U, T Access level: 3
Data type: Unsigned32 / Binary Func. diagram: 2055
Min Max Factory setting
- - 0
