2 Parameters
2.2 List of parameters
SINAMICS DCP
116 List Manual (LH21), 05/2016
Description: Sets the tolerance window for time synchronization.
When this tolerance window is exceeded, an appropriate alarm is output.
Dependency: Refer to: A01099
Description: Sets the delay time for external fault 3.
Dependency: Refer to: p2108, p3111, p3112
Refer to: F07862
Description: Sets the signal source for the enable signal of external fault 3.
External fault 3 is initiated by the following AND logic operation:
- BI: p2108 negated
- BI: p3111
- BI: p3112 negated
Dependency: Refer to: p2108, p3110, p3112
Refer to: F07862
Description: Sets the signal source for the enable signal of external fault 3.
External fault 3 is initiated by the following AND logic operation:
- BI: p2108 negated
- BI: p3111
- BI: p3112 negated
Dependency: Refer to: p2108, p3110, p3112
Refer to: F07862
Description: Sets the signal source for the negated enable signal of external fault 3.
p3109 RTC real time synchronization tolerance window / RTC sync tol
CU_DCP Can be changed: U, T Access level: 3
Data type: Unsigned16 Func. diagram: -
Min Max Factory setting
0 [ms] 1000 [ms] 100 [ms]
p3110 External fault 3 power-up delay / Ext fault 3 t_on
All objects Can be changed: U, T Access level: 3
Data type: Unsigned16 Func. diagram: 2546
Min Max Factory setting
0 [ms] 1000 [ms] 0 [ms]
p3111 BI: External fault 3 enable / Ext fault 3 enab
CU_DCP, TM150,
TM15DI_DO, TM31
Can be changed: U, T Access level: 3
Data type: Unsigned32 / Binary Func. diagram: 2546
Min Max Factory setting
- - 1
p3111[0...n] BI: External fault 3 enable / Ext fault 3 enab
DCP_CTRL Can be changed: U, T Access level: 3
Data type: Unsigned32 / Binary Func. diagram: -
Min Max Factory setting
- - 1
p3112 BI: External fault 3 enable negated / Ext flt 3 enab neg
CU_DCP, TM150,
TM15DI_DO, TM31
Can be changed: U, T Access level: 3
Data type: Unsigned32 / Binary Func. diagram: 2546
Min Max Factory setting
- - 0
