SINAMICS DCP
List Manual (LH21), 05/2016
261
2 Parameters
2.2 List of parameters
The status values have the following meaning:
0: trace inactive.
1: trace records pre-samples.
2: trace waits for trigger event.
3: trace is being recorded.
4: Recording (trace) ended.
Description: Sets the position of the power unit in the converter topology.
Value: 0: Parallel interface not active
10: Master
11: Slave
Note: If value = 0:
The parallel interface is inactive, the hardware does not have to be connected. The power unit operates alone.
Description: Setting to activate/deactivate the bus terminator for the parallel interface.
Value: 0: Bus terminator off
1: Bus terminator on
Note: If value = 0:
The parallel interface is inactive, the hardware does not have to be connected. The power unit operates alone.
Description: Sets the bus address for connecting devices in parallel.
Description: Sets the permissible telegram failure time for the parallel interface.
This setting means that every device connected to the parallel interface can monitor whether it is connected to the
parallel interface.
If a telegram is not received from other devices connected to the parallel interface for longer than the set time, then
BICO output r53310.0 is set = 1 - and for the factory setting, fault F60014 is also output.
Value = 0.0:
Telegram monitoring is deactivated.
Value = 0.001 ... 100.000:
Telegram monitoring is activated.
Note: Telegram monitoring is active in the following cases:
- from the first telegram received error-free after switching on the electronics power supply. The telegram can be
received from any device.
- from the first telegram received error-free after the telegram monitoring responds (as the failure time has expired).
p51800 Power unit topology position / PU topo pos
DCP_CTRL Can be changed: T Access level: 2
Data type: Integer16 Func. diagram: 9350
Min Max Factory setting
0 11 0
p51805 Parallel interface bus terminator / Par_IF bus term
DCP_CTRL Can be changed: U, T Access level: 2
Data type: Integer16 Func. diagram: 9350
Min Max Factory setting
0 1 0
p51806 Parallel interface bus address / Par IF bus addr
DCP_CTRL Can be changed: T Access level: 2
Data type: Unsigned16 Func. diagram: 9350
Min Max Factory setting
0 15 1
p51807 Parallel interface telegram monitoring failure time / Telegr mon t_fail
DCP_CTRL Can be changed: U, T Access level: 2
Data type: FloatingPoint32 Func. diagram: 9350
Min Max Factory setting
0.000 [s] 100.000 [s] 0.100 [s]
