SINAMICS DCP
List Manual (LH21), 05/2016
289
2 Parameters
2.2 List of parameters
Description: Sets the lower threshold value for the undervoltage on side 2.
The reactor current is reduced to zero from this value.
Description: Sets the upper threshold value for the undervoltage on side 2.
The reactor current is reduced from this value.
Description: Sets the lower threshold value for the overvoltage on side 2.
The reactor current is reduced from this value.
Description: Sets the upper threshold value for the overvoltage on side 2.
The reactor current is reduced to zero from this value.
Description: Sets the recovery time for the voltage limiting.
After exiting voltage limiting, the current is ramped-up with the recovery time set here.
Description: Display and connector output for the reactor current setpoint after the voltage limiting.
p55140 Limiting side 2 undervoltage lower / Lim S2 U_under low
DCP_CTRL Can be changed: U, T Access level: 1
Data type: FloatingPoint32 Func. diagram: 6812
Min Max Factory setting
0 [V] 1500 [V] 50 [V]
p55141 Limiting side 2 undervoltage upper / Lim S2 U_under up
DCP_CTRL Can be changed: U, T Access level: 1
Data type: FloatingPoint32 Func. diagram: 6812
Min Max Factory setting
0 [V] 1500 [V] 100 [V]
p55142 Limiting side 2 overvoltage lower / Lim S2 U_over low
DCP_CTRL Can be changed: U, T Access level: 1
Data type: FloatingPoint32 Func. diagram: 6812
Min Max Factory setting
0 [V] 1500 [V] 800 [V]
p55143 Limiting side 2 overvoltage upper / Lim S2 U_over up
DCP_CTRL Can be changed: U, T Access level: 1
Data type: FloatingPoint32 Func. diagram: 6812
Min Max Factory setting
0 [V] 1500 [V] 1000 [V]
p55145 Voltage limiting recovery time / U_lim t_recovery
DCP_CTRL Can be changed: U, T Access level: 2
Data type: FloatingPoint32 Func. diagram: 6812
Min Max Factory setting
0.000 [s] 10.000 [s] 0.500 [s]
r55150 CO: Voltage limiting reactor current setpoint output / U_lim I_react_set
DCP_CTRL Can be changed: - Access level: 2
Data type: FloatingPoint32 Func. diagram: 6812
Min Max Factory setting
- [%] - [%] - [%]
