SINAMICS DCP
List Manual (LH21), 05/2016
129
2 Parameters
2.2 List of parameters
Note: DI/DO: Bidirectional Digital Input/Output
Description: Sets the bidirectional digital inputs/outputs as input or output on the Terminal Module 31 (TM31).
Note: DI/DO: Bidirectional Digital Input/Output
Description: Sets the signal source for terminal DI/DO 0 (X520.2) of Terminal Module 15 (TM15).
Note: Prerequisite: The DI/DO must be set as an output (p4028.0 = 1).
DI/DO: Bidirectional Digital Input/Output
Description: Sets the signal source for the digital output DO 0 (X542.1, X542.2, X542.3) of Terminal Module 31 (TM31).
Digital output 0 of TM31 is a relay output.
If the signal at the binector input p4030 is low, then terminal COM 0 (X542.2) is connected to NC 0 (X542.1). This
connection also matches the mechanical quiescent setting of the relay.
If the signal at the binector input p4030 is high, then terminal COM 0 (X542.2) is connected to NO 0 (X542.3).
Note: DO: Digital Output
NC: Normally Closed contact
NO: Normally Open contact
09 DI/DO 9 (X521.3) Output Input -
10 DI/DO 10 (X521.4) Output Input -
11 DI/DO 11 (X521.5) Output Input -
12 DI/DO 12 (X521.6) Output Input -
13 DI/DO 13 (X521.7) Output Input -
14 DI/DO 14 (X521.8) Output Input -
15 DI/DO 15 (X521.9) Output Input -
16 DI/DO 16 (X522.2) Output Input -
17 DI/DO 17 (X522.3) Output Input -
18 DI/DO 18 (X522.4) Output Input -
19 DI/DO 19 (X522.5) Output Input -
20 DI/DO 20 (X522.6) Output Input -
21 DI/DO 21 (X522.7) Output Input -
22 DI/DO 22 (X522.8) Output Input -
23 DI/DO 23 (X522.9) Output Input -
p4028 TM31 set input or output / TM31 DI or DO
TM31 Can be changed: T Access level: 1
Data type: Unsigned32 Func. diagram: 9549, 9560,
9562
Min Max Factory setting
- - 0000 0000 0000 0000 bin
Bit field: Bit Signal name 1 signal 0 signal FP
08 DI/DO 8 (X541.2) Output Input -
09 DI/DO 9 (X541.3) Output Input -
10 DI/DO 10 (X541.4) Output Input -
11 DI/DO 11 (X541.5) Output Input -
p4030 BI: TM15DI/DO signal source for terminal DI/DO 0 / TM15D S_src DI/DO0
TM15DI_DO Can be changed: U, T Access level: 1
Data type: Unsigned32 / Binary Func. diagram: 9399, 9400
Min Max Factory setting
- - 0
p4030 BI: TM31 signal source for terminal DO 0 / TM31 s_src DO 0
TM31 Can be changed: U, T Access level: 1
Data type: Unsigned32 / Binary Func. diagram: 9549, 9556
Min Max Factory setting
- - 0
