SINAMICS DCP
List Manual (LH21), 05/2016
31
2 Parameters
2.2 List of parameters
Description: Displays the effective Command Data Set (CDS).
Dependency: Refer to: p0810, r0836
Note: The Command Data Set selected using a binector input (e.g. p0810) is displayed using r0836.
Description: Displays the effective Drive Data Set (DDS).
Dependency: Refer to: p0820, p0821, r0837
Description: Executes an automatic device configuration.
In so doing, p0099, p0107 and p0108 are appropriately set.
Value: 0: No selection
15: Drive object type DC_CTRL
Dependency: Refer to: r0098, p0099
Refer to: A01330
Note: For p0097 = 0, p0099 is automatically set to the factory setting.
Description: Displays the automatically detected actual device topology in coded form.
Index: [0] = DRIVE-CLiQ socket X100
[1] = DRIVE-CLiQ socket X101
[2...5] = Reserved
Dependency: Refer to: p0097, p0099
Note: Topology coding: abcd efgh hex
a = 0
b = 0
c = 0
d = no. of motor encoders
e = no. of additional encoders
f = number of Terminal Modules
g = number of Terminal Boards
r0050.0 CO/BO: Command Data Set CDS effective / CDS effective
DCP_CTRL Can be changed: - Access level: 2
Data type: Unsigned8 Func. diagram: 8560
Min Max Factory setting
- - -
Bit field: Bit Signal name 1 signal 0 signal FP
00 CDS eff bit 0 ON OFF -
r0051.0...1 CO/BO: Drive Data Set DDS effective / DDS effective
DCP_CTRL Can be changed: - Access level: 2
Data type: Unsigned8 Func. diagram: 8565
Min Max Factory setting
- - -
Bit field: Bit Signal name 1 signal 0 signal FP
00 DDS eff bit 0 ON OFF -
01 DDS eff bit 1 ON OFF -
p0097 Select drive object type / Select DO type
CU_DCP Can be changed: C1(1) Access level: 1
Data type: Integer16 Func. diagram: -
Min Max Factory setting
0 15 0
r0098[0...5] Actual device topology / Device_act topo
CU_DCP Can be changed: - Access level: 1
Data type: Unsigned32 Func. diagram: -
Min Max Factory setting
- - -
