SINAMICS DCP
List Manual (LH21), 05/2016
67
2 Parameters
2.2 List of parameters
Dependency: Refer to: r2043
Refer to: F01910
Description: Sets the additional monitoring time to monitor the process data received via PROFIBUS.
Enables short bus faults to be compensated.
If no process data is received within this time, then an appropriate message is output.
Recommendation: In the isochronous mode, the additional monitoring time should not be set.
Dependency: Refer to: F01910
Note: For controller STOP, the additional monitoring time is not effective.
Description: Sets the sampling time for the cyclic interface 1 (IF1).
Note: The system only permits certain sampling times and after writing to this parameter, displays the value that has
actually been set.
For clock cycle synchronous operation, the specified bus cycle time applies (Tdp).
Description: Connector output to interconnect PZD (setpoints) with word format received from the fieldbus controller.
Index: [0] = PZD 1
[1] = PZD 2
[2] = PZD 3
[3] = PZD 4
[4] = PZD 5
[5] = PZD 6
[6] = PZD 7
[7] = PZD 8
[8] = PZD 9
[9] = PZD 10
[10] = PZD 11
[11] = PZD 12
[12] = PZD 13
[13] = PZD 14
[14] = PZD 15
[15] = PZD 16
[16] = PZD 17
[17] = PZD 18
[18] = PZD 19
[19] = PZD 20
Note: IF1: Interface 1
p2047 PROFIBUS additional monitoring time / PB suppl t_monit
CU_DCP Can be changed: U, T Access level: 3
Data type: FloatingPoint32 Func. diagram: 2410
Min Max Factory setting
0 [ms] 20000 [ms] 0 [ms]
p2048 IF1 PROFIdrive PZD sampling time / IF1 PZD t_sample
CU_DCP Can be changed: C1(3) Access level: 3
Data type: FloatingPoint32 Func. diagram: -
Min Max Factory setting
1.00 [ms] 16.00 [ms] 4.00 [ms]
r2050[0...19] CO: IF1 PROFIdrive PZD receive word / IF1 PZD recv word
CU_DCP Can be changed: - Access level: 3
Data type: Integer16 Func. diagram: -
Min Max Factory setting
- - -
