Siemens sinamics dcp - Fig. 3-24 3102 - Function generator

3 Function diagrams 3.7 Auxiliary functions
SINAMICS DCP
342 List Manual (LH21), 05/2016
Fig. 3-24 3102 – Function generator
fp_3102_89.vsd
12345678
- 3102 -
SINAMICS DCP
03.06.2014 v 1.2
DO: CU_DC
- Function generator
Function diagram
p04830
[1020.7]
p4829
p4824
p4826
p4827
p4821
p4828
p4825
p4829
p4824
p4826
p4827
p4821
p4828
p4822
p4829
p4824
p4826
p4827
p4821
p4828
p4829
p4824
p4826
p4827
p4821
p4828
p4829
p4824
p4826
p4827
p4823
p4828
Square
Triangle Sine
Staircase Binary noise
Only value "0" meaningful for
p4810
r04818[0]
FG outp_sig [%]
r04806.00
FG status signal
FG control
0...3
p04800 (0)
p04819
(1)
FG control
FG status
r04805
FG operating mode
0...99
p04810 (0)
FG signal shape
1...5
p04820 (1)
FG period duration
0.00...60000.00 [ms]
p04821 (1000.00)
FG pulse width
0.00...60000.00 [ms]
p04822 (500.00)
FG bandwidth
0.0025...16000.0000 [Hz]
p04823 (4000.0000)
p04824 (5.00)
-1600.00...1600.00 [%]
FG amplitude
p04825 (7.00)
-1600.00...1600.00 [%]
FG 2nd amplitude
p04826 (0.00)
-1600.00...1600.00 [%]
FG offset
p04827 (32.00)
0.00...100000.00 [ms]
FG ramp-up offset
p04828 (-100.00)
-10000.00...0.00 [%]
FG lower limit
p04829 (100.00)
0.00...10000.00 [%]
FG upper limit
FG amplitude scal
0.00000...200.00000 [%]
p04831 (100.00000)
