SINAMICS DCP
List Manual (LH21), 05/2016
229
2 Parameters
2.2 List of parameters
Description: Displays the directory and name of the file whose status as shipped from the factory was identified as impermissible.
Dependency: Refer to: r9926
Refer to: A01016
Note: The directory and name of the file is displayed in the ASCII code.
Description: Displays the status when the firmware is checked when the system is booted.
0: Firmware not yet checked.
1: Check running.
2: Check successfully completed.
3: Check indicates an error.
Dependency: Refer to: r9925
Refer to: A01016
Description: Displays the measured system utilization.
The higher the value displayed, the higher the system utilization.
Index: [0] = Computing time utilization (min)
[1] = Computing time utilization (averaged)
[2] = Computing time utilization (max)
[3] = Largest total utilization (min)
[4] = Largest total utilization (averaged)
[5] = Largest total utilization (max)
[6] = Reserved
[7] = Reserved
Dependency: Refer to: r9976, r9979, r9980, r9981
Refer to: F01054, F01205
Note: Re index 3 ... 5:
The total utilizations are determined using all sampling times used. The largest total utilizations are mapped here.
The sampling time with the largest total utilization is displayed in r9979.
Total utilization:
Computing time load of sampling time involved including load from higher-priority sampling times (interrupts).
Description: Displays the system utilization.
If the utilization is greater than 100%, fault F01054 is output.
r9925[0...99] Firmware file incorrect / FW file incorr
CU_DCP Can be changed: - Access level: 2
Data type: Unsigned8 Func. diagram: -
Min Max Factory setting
- - -
r9926 Firmware check status / FW check status
CU_DCP Can be changed: - Access level: 2
Data type: Unsigned8 Func. diagram: -
Min Max Factory setting
- - -
r9975[0...7] System utilization measured / Sys util meas
CU_DCP Can be changed: - Access level: 4
Data type: FloatingPoint32 Func. diagram: -
Min Max Factory setting
- [%] - [%] - [%]
r9976[0...7] System utilization / Sys util
CU_DCP Can be changed: - Access level: 3
Data type: FloatingPoint32 Func. diagram: -
Min Max Factory setting
- [%] - [%] - [%]
