SINAMICS DCP
List Manual (LH21), 05/2016
299
2 Parameters
2.2 List of parameters
Dependency: Refer to: p55456
Note: This parameter is only active for device types with variable-speed fans.
30 kW device:
- the fans are not variable-speed fans.
- parameter p55456 is inactive.
120 kW device:
- the fans are variable-speed fans.
- parameter p55456 is active.
Description: Display and BICO output for the state of the device fan.
Description: Displays the operating hours for the device fan.
Description: Sets the service life for the device fan.
Dependency: Refer to: A60510
Note: An appropriate alarm is issued 500 hours before the set service life expires.
Description: Setting to reset the operating hours of the device fan that have accumulated.
Value: 0: Inactive
1: Reset
Dependency: Refer to: r55470
Note: Procedure to reset the operating hours:
Set p55472 = 1
--> the operating hours counter (r55470) is set to zero.
--> the parameter is automatically set to zero after this is done.
r55460.0...1 CO/BO: Device fan state / Dev fan state
DCP_CTRL Can be changed: - Access level: 2
Data type: Unsigned16 Func. diagram: 6845
Min Max Factory setting
- - -
Bit field: Bit Signal name 1 signal 0 signal FP
00 Switch on fan On Off 6845
01 Switch on fan inverted On Off 6845
r55470 Device fan operating hours display / Dev_fan h disp
DCP_CTRL Can be changed: - Access level: 2
Data type: FloatingPoint32 Func. diagram: 6845
Min Max Factory setting
- [h] - [h] - [h]
p55471 Device fan service life / Dev_fan serv life
DCP_CTRL Can be changed: U, T Access level: 2
Data type: FloatingPoint32 Func. diagram: 6845
Min Max Factory setting
0 [h] 1000000 [h] 30000 [h]
p55472 Device fan reset operating hours / Dev_fan reset h
DCP_CTRL Can be changed: U, T Access level: 2
Data type: Integer16 Func. diagram: 6845
Min Max Factory setting
0 1 0
