SINAMICS DCP
List Manual (LH21), 05/2016
445
4 Faults and alarms
4.2 List of faults and alarms
F08010 (N, A) TB: Analog-digital converter
Drive object: TM150, TM15DI_DO, TM31
Cause: The analog/digital converter on Terminal Board 30 has not supplied any converted data.
Remedy: - check the power supply.
- replace Terminal Board 30.
F08500 (A) COMM BOARD: Monitoring time configuration expired
Drive object: All objects
Cause: The monitoring time for the configuration has expired.
Fault value (r0949, interpret decimal):
0: The transfer time of the send configuration data has been exceeded.
1: The transfer time of the receive configuration data has been exceeded.
Remedy: Check communications link.
F08501 (N, A) PN/COMM BOARD: Setpoint timeout
Drive object: All objects
Cause: The reception of setpoints from the COMM BOARD has been interrupted.
- bus connection interrupted.
- controller switched off.
- controller set into the STOP state.
- COMM BOARD defective.
Remedy: - Restore the bus connection and set the controller to RUN.
- check the set monitoring time if the error persists (p2040).
See also: p8840 (COMM BOARD monitoring time)
F08502 (A) PN/COMM BOARD: Monitoring time sign-of-life expired
Drive object: All objects
Cause: The monitoring time for the sign-of-life counter has expired.
The connection to the COMM BOARD was interrupted.
Remedy: - check communications link.
- check COMM BOARD.
A08504 (F) PN/COMM BOARD: Internal cyclic data transfer error
Drive object: All objects
Cause: The cyclic actual and/or setpoint values were not transferred within the specified times.
Alarm value (r2124, interpret decimal):
Only for internal Siemens troubleshooting.
Remedy: Check the parameterizing telegram (Ti, To, Tdp, etc.).
F08510 (A) PN/COMM BOARD: Send configuration data invalid
Drive object: All objects
Cause: COMM BOARD did not accept the send-configuration data.
Fault value (r0949, interpret decimal):
Return value of the send-configuration data check.
Remedy: Check the send configuration data.
A08511 (F) PN/COMM BOARD: Receive configuration data invalid
Drive object: All objects
Cause: The drive unit did not accept the receive configuration data.
Alarm value (r2124, interpret decimal):
Return value of the receive configuration data check.
1: Connection established to more drive objects than configured in the device. The drive objects for process data
exchange and their sequence are defined in p0978.
2: Too many PZD data words for output or input to a drive object. The number of possible PZD items in a drive object
is determined by the number of indices in r2050/p2051 for PZD IF1, and in r8850/p8851 for PZD IF2.
3: Uneven number of bytes for input or output.
