Siemens sinamics dcp - r55151 CO: Correction current controller output; Corr_ctrl outp; p55155 Current actual value external activation; I_act val ext act; p55156 CI: Current actual value external signal source; I_act ext s_src; p55160 Correction current controller integrating time; Corr_ctrl t_int

2 Parameters
2.2 List of parameters
SINAMICS DCP
290 List Manual (LH21), 05/2016
Description: Display and connector output for the correction current controller output.
Description: Setting to activate the external current actual value
Value: 0: Not activated
1: Activated
Description: Sets the signal source for the external current actual value.
Description: Sets the integrating time for correction current controller.
Description: Sets the limiting for correction current controller.
Description: Display and connector output for the reactor current setpoint after dynamic voltage limiting.
Description: Display and connector output for the reactor current setpoint of the main current controller.
r55151 CO: Correction current controller output / Corr_ctrl outp
DCP_CTRL Can be changed: - Access level: 2
Data type: FloatingPoint32 Func. diagram: 6806
Min Max Factory setting
- [%] - [%] - [%]
p55155 Current actual value external activation / I_act val ext act
DCP_CTRL Can be changed: T Access level: 3
Data type: Integer16 Func. diagram: 6806
Min Max Factory setting
0 1 0
p55156 CI: Current actual value external signal source / I_act ext s_src
DCP_CTRL Can be changed: T Access level: 3
Data type: Unsigned32 / FloatingPoint32 Func. diagram: 6806
Min Max Factory setting
- - 0
p55160 Correction current controller integrating time / Corr_ctrl t_int
DCP_CTRL Can be changed: U, T Access level: 2
Data type: FloatingPoint32 Func. diagram: 6806
Min Max Factory setting
1 [ms] 5000 [ms] 1000 [ms]
p55161 Correction current controller limiting / Corr_ctrl lim
DCP_CTRL Can be changed: U, T Access level: 2
Data type: FloatingPoint32 Func. diagram: 6806
Min Max Factory setting
0.000 [%] 50.000 [%] 10.000 [%]
r55170 CO: Limiting the reactor current setpoint after U dyn / Lim I_ re_sp U dyn
DCP_CTRL Can be changed: - Access level: 2
Data type: FloatingPoint32 Func. diagram: 6817
Min Max Factory setting
- [%] - [%] - [%]
r55172 CO: Main current controller reactor current setpoint / Mn ctr I_react_set
DCP_CTRL Can be changed: - Access level: 2
Data type: FloatingPoint32 Func. diagram: 6820
Min Max Factory setting
- [%] - [%] - [%]
