SINAMICS DCP
List Manual (LH21), 05/2016
103
2 Parameters
2.2 List of parameters
Note: An external alarm is triggered with a 1/0 signal.
Description: Sets the signal source for external alarm 2.
Dependency: Refer to: A07851
Note: An external alarm is triggered with a 1/0 signal.
Description: Sets the signal source for external alarm 3.
Dependency: Refer to: A07852
Note: An external alarm is triggered with a 1/0 signal.
Description: Sets the signal source for external alarm 3.
Dependency: Refer to: A07852
Note: An external alarm is triggered with a 1/0 signal.
Description: Selects faults or alarms for which the message type should be changed.
Dependency: Selects the fault or alarm selection and sets the required type of message realized under the same index.
Refer to: p2119
Note: Re-parameterization is also possible if a message is present. The change only becomes effective after the message
has gone.
Description: Selects faults or alarms for which the message type should be changed.
Dependency: Selects the fault or alarm selection and sets the required type of message realized under the same index.
Refer to: p2119
Note: Re-parameterization is also possible if a message is present. The change only becomes effective after the message
has gone.
p2116[0...n] BI: External alarm 2 / External alarm 2
DCP_CTRL Can be changed: U, T Access level: 3
Data type: Unsigned32 / Binary Func. diagram: 2546
Min Max Factory setting
- - 1
p2117 BI: External alarm 3 / External alarm 3
CU_DCP, TM150,
TM15DI_DO, TM31
Can be changed: U, T Access level: 3
Data type: Unsigned32 / Binary Func. diagram: -
Min Max Factory setting
- - 1
p2117[0...n] BI: External alarm 3 / External alarm 3
DCP_CTRL Can be changed: U, T Access level: 3
Data type: Unsigned32 / Binary Func. diagram: 2546
Min Max Factory setting
- - 1
p2118[0...19] Change message type message number / Chng type msg_no
CU_DCP, TM150,
TM15DI_DO, TM31
Can be changed: U, T Access level: 3
Data type: Unsigned16 Func. diagram: 8050, 8075
Min Max Factory setting
0 65535 0
p2118[0...19] Change message type message number / Chng type msg_no
DCP_CTRL Can be changed: U, T Access level: 3
Data type: Unsigned16 Func. diagram: 8075
Min Max Factory setting
0 65535 0
