2 Parameters
2.1 Overview of parameters
SINAMICS DCP
14 List Manual (LH21), 05/2016
2.1 Overview of parameters
Basic structure of the parameter descriptions
The data in the following example has been chosen at random. The table below contains the
maximum amount of information that can be included in a parameter description. Some of the
information is optional.
The "List of parameters" (Page 22) has the following structure:
- - - - - - - - - - - - Start of example - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Description: Text
Value: 0: Name and meaning of value 0
1: Name and meaning of value 1
2: Name and meaning of value 2
etc.
Recommendation: Text
Index: [0] = Name and meaning of index 0
[1] = Name and meaning of index 1
[2] = Name and meaning of index 2
etc.
Dependency: Text
Refer to: pxxxx, rxxxx
Refer to: Fxxxxx, Axxxxx
Note: Information that might be useful.
- - - - - - - - - - - - End of example - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
The individual pieces of information are described in detail below.
pxxxx[0...n] BICO: Full parameter name / abbreviated name
Drive object (function
module)
Can be changed: C1(x), C2(x), U, T Access level: 2
Data type: Unsigned32 / Integer16 Function diagram: 8070
Min. Max Factory setting
0.00 [Nm] 10.00 [Nm] 0.00 [Arms]
Bit field: Bit Signal name 1 signal 0 signal FP
00 Name and meaning of bit 0 Yes No 8060
01 Name and meaning of bit 1 Yes No -
02 Name and meaning of bit 2 Yes No 8065
etc.
Danger: Warning: Caution: Safety notices with a warning triangle
Notice: Safety notices without a warning triangle
