SINAMICS DCP
List Manual (LH21), 05/2016
247
2 Parameters
2.2 List of parameters
Description: Sets the signal source to enable analog input 1 (AI 1, X177.27/28) on the CUD.
Note: AI: Analog Input
Description: Sets the scaling for analog input 2 (AI 2, X177.29/30) on the CUD.
The value indicates the percentage value for mapping an input voltage of 10 V at the analog input.
Example:
p50721 = 90%
--> 10 V is scaled to 90%
--> 5 V corresponds to 45%
Note: AI: Analog Input
Description: Sets the offset for analog input 2 (AI 2, X177.29/30) on the CUD.
Note: AI: Analog Input
Description: Sets the signal processing mode for analog input 2 (AI 2, X177.29/30) on the CUD.
Value: 0: Signal not influenced
1: Signal absolute value generation
2: Signal inverted
3: Signal absolute value generation inverted
Note: AI: Analog Input
Description: Sets the signal source for inverting the signal from analog input 2 (AI 2, X177.29/30) on the CUD.
1 signal: inversion
0 signal: no inversion
Note: AI: Analog Input
p50716 BI: CUD analog input 1 signal source for enable / CUD AI 1 ena s_src
DCP_CTRL Can be changed: T Access level: 3
Data type: Unsigned32 / Binary Func. diagram: 2080
Min Max Factory setting
- - 1
p50721[0...n] CUD analog input 2 scaling / CUD AI 2 scal
DCP_CTRL Can be changed: U, T Access level: 3
Data type: FloatingPoint32 Func. diagram: 2080
Min Max Factory setting
-1000.0 [%] 1000.0 [%] 100.0 [%]
p50722 CUD analog input 2 offset / CUD AI 2 offs
DCP_CTRL Can be changed: U, T Access level: 3
Data type: FloatingPoint32 Func. diagram: 2080
Min Max Factory setting
-200.00 [%] 200.00 [%] 0.00 [%]
p50723 CUD analog input 2 signal processing / CUD AI 2 sig proc
DCP_CTRL Can be changed: T Access level: 3
Data type: Integer16 Func. diagram: 2080
Min Max Factory setting
0 3 0
p50724 BI: CUD analog input 2 inversion / CUD AI 2 inv
DCP_CTRL Can be changed: T Access level: 3
Data type: Unsigned32 / Binary Func. diagram: 2080
Min Max Factory setting
- - 0
