2 Parameters
2.2 List of parameters
SINAMICS DCP
242 List Manual (LH21), 05/2016
Description: Sets the signal level for fixed bit 1.
This value is available at binector output r53230.1 for interconnection.
Value: 0: Low
1: High
Dependency: Refer to: r53230
Description: Sets the signal level for fixed bit 2.
This value is available at binector output r53230.2 for interconnection.
Value: 0: Low
1: High
Dependency: Refer to: r53230
Description: Sets the signal level for fixed bit 3.
This value is available at binector output r53230.3 for interconnection.
Value: 0: Low
1: High
Dependency: Refer to: r53230
Description: Sets the signal level for fixed bit 4.
This value is available at binector output r53230.4 for interconnection.
Value: 0: Low
1: High
Dependency: Refer to: r53230
Description: Sets the signal level for fixed bit 5.
This value is available at binector output r53230.5 for interconnection.
Value: 0: Low
1: High
p50422 Fixed bit 1 / Fix bit 1
DCP_CTRL Can be changed: U, T Access level: 3
Data type: Integer16 Func. diagram: 3100
Min Max Factory setting
0 1 0
p50423 Fixed bit 2 / Fix bit 2
DCP_CTRL Can be changed: U, T Access level: 3
Data type: Integer16 Func. diagram: 3100
Min Max Factory setting
0 1 0
p50424 Fixed bit 3 / Fix bit 3
DCP_CTRL Can be changed: U, T Access level: 3
Data type: Integer16 Func. diagram: 3100
Min Max Factory setting
0 1 0
p50425 Fixed bit 4 / Fix bit 4
DCP_CTRL Can be changed: U, T Access level: 3
Data type: Integer16 Func. diagram: 3100
Min Max Factory setting
0 1 0
p50426 Fixed bit 5 / Fix bit 5
DCP_CTRL Can be changed: U, T Access level: 3
Data type: Integer16 Func. diagram: 3100
Min Max Factory setting
0 1 0
