Siemens sinamics dcp - p4110[0...11] TM150 wire resistance value; TM150 R_wire value; p4111[0...2] TM150 group channel assignment; TM150 grp channel

SINAMICS DCP
List Manual (LH21), 05/2016
155
2 Parameters
2.2 List of parameters
Description: Sets and displays the wire resistance for Terminal Module 150 (TM150).
The value is used for the automatic conductor calibration.
The value is automatically set by starting the wire resistance measurement (p4109[0...11]) of the corresponding
channel.
Index: [0] = Temperature channel 0
[1] = Temperature channel 1
[2] = Temperature channel 2
[3] = Temperature channel 3
[4] = Temperature channel 4
[5] = Temperature channel 5
[6] = Temperature channel 6
[7] = Temperature channel 7
[8] = Temperature channel 8
[9] = Temperature channel 9
[10] = Temperature channel 10
[11] = Temperature channel 11
Dependency: Refer to: p4109
Notice: Wire resistance measurement is only possible for 1x2 or 2x2 wire evaluation (p4108[0...5] = 0, 1).
Note: Automatic conductor calibration is deactivated using p4110[0...11] = 0.
Description: Assigns the temperature channels to groups for the Terminal Module 150 (TM150)
For each group, the following calculated values are provided from the temperature actual values (r4105[0...11]):
- Maximum value (r4112[0...2])
- Minimum value (r4113[0...2])
- average value (r4114[0...2])
Index: [0] = Group 0
[1] = Group 1
[2] = Group 2
Dependency: Refer to: r4105, r4112, r4113, r4114
p4110[0...11] TM150 wire resistance value / TM150 R_wire value
TM150 Can be changed: T Access level: 1
Data type: FloatingPoint32 Func. diagram: 9626, 9627
Min Max Factory setting
0.00 [ohm] 3000.00 [ohm] 0.00 [ohm]
p4111[0...2] TM150 group channel assignment / TM150 grp channel
TM150 Can be changed: T Access level: 1
Data type: Unsigned16 Func. diagram: 9625
Min Max Factory setting
- - 0000 0000 0000 0000 bin
Bit field: Bit Signal name 1 signal 0 signal FP
00 Temperature channel 0 Yes No -
01 Temperature channel 1 Yes No -
02 Temperature channel 2 Yes No -
03 Temperature channel 3 Yes No -
04 Temperature channel 4 Yes No -
05 Temperature channel 5 Yes No -
06 Temperature channel 6 Yes No -
07 Temperature channel 7 Yes No -
08 Temperature channel 8 Yes No -
09 Temperature channel 9 Yes No -
10 Temperature channel 10 Yes No -
11 Temperature channel 11 Yes No -
