SINAMICS DCP
List Manual (LH21), 05/2016
209
2 Parameters
2.2 List of parameters
[26] = PZD 27
[27] = PZD 28
[28] = PZD 29
[29] = PZD 30
[30] = PZD 31
[31] = PZD 32
[32] = PZD 33
[33] = PZD 34
[34] = PZD 35
[35] = PZD 36
[36] = PZD 37
[37] = PZD 38
[38] = PZD 39
[39] = PZD 40
[40] = PZD 41
[41] = PZD 42
[42] = PZD 43
[43] = PZD 44
[44] = PZD 45
[45] = PZD 46
[46] = PZD 47
[47] = PZD 48
[48] = PZD 49
[49] = PZD 50
[50] = PZD 51
[51] = PZD 52
[52] = PZD 53
[53] = PZD 54
[54] = PZD 55
[55] = PZD 56
[56] = PZD 57
[57] = PZD 58
[58] = PZD 59
[59] = PZD 60
[60] = PZD 61
[61] = PZD 62
[62] = PZD 63
[63] = PZD 64
Note: IF2: Interface 2
Value range:
0 - 242: Byte offset
255: Not assigned
Description: Displays the byte offset of the PZD in the send telegram.
Index: [0] = PZD 1
[1] = PZD 2
[2] = PZD 3
[3] = PZD 4
[4] = PZD 5
Description: Selects bits to be sent via interface 2.
r8876[0...4] IF2 diagnostics telegram offset PZD send / IF2 diag offs send
TM150, TM15DI_DO,
TM31
Can be changed: - Access level: 3
Data type: Unsigned16 Func. diagram: -
Min Max Factory setting
- - -
p8880[0...15] BI: IF2 binector-connector converter status word 1 / Bin/con ZSW1
DCP_CTRL Can be changed: U, T Access level: 3
Data type: Unsigned32 / Binary Func. diagram: 2489
Min Max Factory setting
- - 0
